Pride Mobility SC155 User Manual
Page 17
17
Rally/RevF/September 03
www.pridemobility.com
7.5"
13"
18.5"
16.5"
32"
34"
-
-
80˚
16"
(22" - 29")
18"
21"
44"Length
(4-Wheel Rally)
54"
4-Wheel Rally Turning Radius
3"
3-Wheel Rally Turning Radius
39"
41"Length
(3-Wheel Rally)
Figure 4. Rally Dimensions
I V . S P E C I F I C A T I O N S
Figure 4A. Rally Tire Dimensions (Front)
9"
2.5"
Figure 4B. Rally Tire Dimensions (Rear)
8"
2"
