Patton’s IPLink WAN Gateway Routers are a complete all-in-one network access device which easily connects your
IP/LAN to any T1/E1, X.21, or V.35 network interface.
High Speed WAN Routers
IPLink ™ Router Products
Patton IPLink ™ Models 2603, 2621, & 2635
T
he Models 2603, 2621, and 2635 Gateway
Routers are the ideal solution for connect-
ing any small to medium enterprise or
remote office to an IP/Internet network using stan-
dard telco and WAN interfaces.
Combining ease-of-use with a full suite of
LAN/WAN routing features, the IPLink routers pro-
vide selectable bridging or routing functionality
along with advanced IP features such as
NAT/NAPT, Firewall, and DHCP. A complete set of
configurable FR/PPP/IP WAN protocols allow a
wide range of choices when connecting branches
via common WAN services. The IPLink Routers
boast easy installation offering Console/VT-100,
Telnet, and HTTP/SNMP management options.
All IPLink routers come with an auto-sensing full-
duplex 10/100Base-T Ethernet port, cross-over
switch, and internal power supply. The Model 2603
is equipped with an integrated T1/E1 CSU/DSU for
connection to full and fractional T1/E1 services.
The Model 2621 is equipped with an X.21 inter-
face, and the Model 2635 comes with a V.35 inter-
face.
Patton’s new series of high-speed routers offer the
versatility and reliability demanded for business-
class applications at the most affordable price.
Visit www.patton.com for more information.
IPLink Gateway Router
Model 2603—T1/E1 Interface
Model 2635—V.35 Interface
Model 2621—X.21 Interface
Interface Options
