Frequency Response:
Mic Input to L - R Output
Line Input to L - R Output
To Power Amplifier Output 20 Hz - 20 kHz +0 dB/-1 dB
20 Hz - 20 kHz +0 dB/-1 dB
20 Hz - 20 kHz +0 dB/-1 dB
14
Graphic Equalizer:
Filter Bandwidth
Filter Frequencies
Maximum Boost and Cut 1 octave
63, 125, 250, 500, 1 k, 2 k, 4 k, 8 k, 16 k
+12 dB Boost, -12 dB Cut
Total Harmonic Distortion (THD):
< 0.01% 20 Hz - 20 kHz mic input to L/R Mon. output at nominal level (20 Hz - 80 kHz BW)
< 0.01% 20 Hz - 20 kHz line input to L/R output at output at nominal level (20 Hz - 80 kHz BW)
< .005% Typical at 1 kHz
XR ® 696 Hum and Noise:
Output Residual Noise S/N Ratio Test Conditions
Ref: 0 dBu Ref: 2 dBu
Main Left -98 dBu -100 dB All controls down
and Right
-89 dBu -91 dB One channel nominal, master
nominal
-81 dBu -83 dB Master level nominal,
Channel level nominal, Mic
inputs terminated @ 150 Ohms
Monitor -96 dBu -98 dB All controls down
-90 dBu -92 dB One channel nominal, master
nominal
-81 dBu -83 dB Master level nominal,
Channel level nominal, Mic
inputs terminated @ 150 Ohms
(Hum and noise measurements: 22 Hz to 22 kHz BW)
S/N Ratio:
> 85 dB below rated output (500 W/channel), mic/line to speaker output
Equivalent Input Noise (EIN):
-121.5 dBu (Input terminated with 150 Ohms)
Crosstalk:
> 80 dB adjacent input channels (20 Hz - 20 kHz)
> 70 dB left to right outputs (20 Hz - 20 kHz)
Common Mode Rejection Ratio (Mic Input):
50 dB min. (20 Hz - 20 kHz)
60 dB typical @ 1 kHz
