Model 3101RC Quick Start Guide 7
Table 2. Pin Assignment of Console Cable (DTE Relative)
Signal Type Abbr. DB-9F RJ-45M Pin
Common Ground GND Pin 5 Pin 4
Transmitted Data TxD Pin 3 Pin 6
Received Data RxD Pin 2 Pin 5
Data Terminal Ready DTR Not used Not used
Data Set Ready DSR Not used Not used
Request To Send RTS Not used Not used
Clear To Send CTS Not used Not used
Carrier Detect DCD Not used Not used
Ring Indicator RI Not used NA
