7
KEY PART
NO. NO.
DESCRIPTION
2
532 19 42-63 Drawbar
5
532 41 17-64 Dash
14
532 19 45-88 Hood
15
532 18 97-54 Lens Grille LH
18
532 18 38-28 Grille (Included Key #'s 15, 25,191)
25
532 18 97-55 Lens Grille RH
36
817 06 05-12 Screw 5/16-18 x 3/4
37
532 42 09-86 Fender
68
817 49 05-08 Screw THDROL 5/16-18 x 1/2
130 532 41 63-58 Screw #10 x 0.750 BOS Thread
137 532 18 49-21 Bumper Hood
138 532 40 97-30 Cupholder
150 532 18 43-22 Duct Heat Hood
151 532 40 78-07 Bracket Pivot
152 532 19 43-29 Shield Browning/Debris
159 817 00 06-12 Screw Hexwsh Thdrol 3/8-16 x 3/4
162 532 14 24-32 Screw Hex Wsh Hi-Lo 1/4 x 1/2 unc
175 532 19 32-43 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8 Wshd Qdrx
177 532 19 52-28 Bushing Steering
180 532 19 42-60 Chassis
181 532 40 47-96 Bushing Mtg. Fender Crgo.
182 532 19 30-57 Dash Lower
183 874 78 05-20 Bolt Fin Hex 5/16-18 x 1-1/4
186 532 18 97-53 Insert Grille
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
196 532 4145-81
Console Asm. Deck Lift
197 532 40 91-67 Rod Pivot Chassis
207 532 18 38-33 Bezel RH
208 532 18 38-32 Bezel LH
228 532 19 51-61 Stud Fastener
235 532 40 61-29 Spacer Fender
236 873 93 05-00 Nut Center Lock 5/16-18 unc
287 817 60 04-06 Screw Hex Washead 1/4-20 x 3/8
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. PP18542 (96041013900), PRODUCT NO. 960 41 01-39
CHASSIS AND ENCLOSURES 39
