13
KEY PART
NO. NO.
DESCRIPTION
1
532 19 45-95 Wheel, Steering
2
532 18 47-06 Axle Asm.
4
532 40 30-87 Spindle Asm., LH
5
532 40 30-88 Spindle Asm., RH
6
532 12 49-31 Bearing, Race Thrust Harden
7
532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
8
812 00 00-29 Ring, Clip #T5304-75
9
532 12 12-32 Cap, Spindle
13
532 12 17-49 Washer 25/32 x 1-1/4 x 16 Ga.
14
810 04 06-00 Washer, Lock Hvy Hlcl Spr 3/8
15
873 54 06-00 Nut, Crown Lock 3/8-24 unf
16
532 19 60-74 Shaft Steering
19
532 19 47-29 Plate Steering
20
532 41 12-91 Boot, Steering
21
532 18 67-37 Adapter, Wheel Steering
22
532 19 48-45 Bushing, Strg. Blk
26
532 19 46-03 Insert, Wheel Steering
28
817 00 06-12 Screw 3/8-16 x 3/4
33
810 04 05-00 Washer Lock Hvy HLCL Spr 5/16
35
532 19 47-32 Gear, Sector Plate
45
819 11 38-12 Washer 11/32 ID x 2 3/8 OD x 12 Ga.
50
873 90 06-00 Nut Lock 3/8-16 unc
53
532 18 89-67 Washer Hardened .793 x 1.637 x .060
54
874 76 06-36 Bolt Hex 3/8-16 unc x 2-1/4
55
532 41 47-36 Spacer Brace Axle
57
532 40 74-65 Bracket Upstop
58
532 19 47-47 Bolt Shoulder Sector Pivot CFM
59
532 19 47-48 Washer Thrust Sector Steering
60
873 97 10-00 Nut Flange Lock 5/8-11
61
532 19 47-40 Draglink, LH
62
532 19 47-41 Draglink, RH
63
817 00 05-12 Screw 5/16-18 x 3/4
64
532 19 98-49 Retainer Clip Spring Steering
65
532 19 47-34 Brace Axle Front
66
871 02 07-48 Bolt Hex Fghd 7/16-14 x 3 Serr
67
532 19 47-37 Bushing PM Front Axle
68
873 90 07-00 Nut Lock Flange 7/16-14 Gr. 5
69
532 19 91-62 Washer 1.5 x .505 x .118
70
532 19 61-97 Bracket Deck Susp. Front
71
532 19 60-75 Shaft Ext Steering
72
874 78 05-72 Bolt Fin Hex 5/16-18 unc 4.5 Gr. 5
78
532 05 70-79 Washer Thrust .515 x .750 x .033
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. PP18542 (96041013900), PRODUCT NO. 960 41 01-39
STEERING ASSEMBLY 41
41
