50
Sensaphone ® ISACC Instruction Manual
Maximum Operating Voltage 250VAC
125VDC
Maximum Operating Current 5A (AC/DC)
Maximum Switching Capacity 1,250VA, 150W
BUZZER:
Sound Output
80dB at 30cm
Frequency 400Hz +50Hz
SOLID STATE RELAY SPECIFICATIONS
AC Output Module (FGD-0015):
Voltage range:
24 - 140 Vrms
Max current: 3 Arms
Min current: 20 mArms
Typical leakage current: 2 mArms at 120 Vrms
DC Output Module (FGD-0016):
Voltage range:
5 - 60 V DC
Max current: 3 A DC
Min current: 20 mA DC
Typical leakage: .5 mA at 32 V DC
High Power Solid State Relay (FGD-0020):
Voltage range:
24 - 140 Vrms
Max current: 25 Arms
Min current: 50 mArms
Typical leakage: 7.5 mArms at 140 Vrms
