23
Ap
pendi
x
Glossary
➲ Glossary ➞ Appendix of the Operation Manual
Specifications
General
Rated power source ............ 14.4 V DC
(10.8 V to 15.1 V allowable)
Grounding system ............... Negative type
Maximum current consumption
................................... 10.0 A
Dimensions (W ✕ H ✕ D):
DIN
Chassis......................... 178 ✕ 100 ✕ 165 mm
(7 ✕ 3-7/8 ✕ 6-1/2 in.)
Nose ............................. 170 ✕ 96 ✕ 16 mm
(6-3/4 ✕ 3-3/4 ✕ 5/8 in.)
Weight .................................. 2.9 kg (6.4 lbs)
HDD...................................... 30 GB
Navigation
GPS Receiver:
System.......................... L1, C/Acode GPS
SPS (Standard Positioning Service)
Reception system........ 8-channel multi-channel
reception system
Reception frequency ... 1 575.42 MHz
Sensitivity ..................... –130 dBm
Position update frequency
................................... Approx. once per second
GPS antenna:
Antenna........................ Micro strip flat antenna/
right-handed helical polari-
zation
Antenna cable ............. 5.0 m (16 ft. 5 in.)
Dimensions (W ✕ H ✕ D)
................................... 33 ✕ 13 ✕ 36 mm
(1-1/4 ✕ 1/2 ✕ 1-3/8 in.)
Weight .......................... 105 g(0.23 lbs)
Display
Screen size/aspect ratio ..... 7.0 inch wide/16:9
(effective display area: 156 ✕ 82 mm) (6-1/8 ✕ 3-1/4 in.)
Pixels .................................... 336 960 (1 440 ✕ 234)
Type ...................................... TFT active matrix, transmis-
sive type
Color system ........................ NTSC
Operating temperature range
........................................... +14
°F
to +122
°F
Storage temperature range
........................................... –4
°F
to +176
°F
Angle adjustment................ 0° to 21°
(initial settings: 0°)
Audio
Continuous power output is 22 W per channel minimum
into 4 ohms, both channels driven 50 Hz to 15 000 Hz
with no more than 5% THD.
Maximum power output ..... 50 W ✕ 4
50 W ✕ 2 ch/4 Ω + 70 W ✕ 1
ch/2 Ω (for subwoofer)
Load impedance.................. 4 Ω (4 Ω to 8 Ω [2 Ω for 1 ch]
allowable)
Preout max output level/output impedance
........................................... 2.0 V/1k Ω
