Type Cap Lumen Colour Colour Efficacy Lumen EOC
base output designation temp maintenance
lm K Im/W 10,000 hrs % 8711500
/830
MASTER PL-H
60W/830/4P A 2G8 4000 warm white 3000 67 85 26407725
MASTER PL-H
85W/830/4P A 2G8 6000 warm white 3000 69 85 26411425
MASTER PL-H
120W/830/4P A 2G8 9000 warm white 3000 73 85 26403925
/840
MASTER PL-H
60W/840/4P A 2G8 4000 cool white 4000 67 85 26409125
MASTER PL-H
85W/840/4P A 2G8 6000 cool white 4000 69 85 26423725
MASTER PL-H
120W/840/4P A 2G8 9000 cool white 4000 73 85 26405325
MASTER PL-H lamps and gear
Ballast Lamp Power Max. cable cap 1 ) TC Oper 2 ) EOC
factor lp-lp/lp-gnd max ˚C Freq. (kHz)
8711500
Gear: One gear type for all lamps.
HF-P PL-H 1 60-120 PL-H 60W 0.96 150/150 75 46 92875730
HF-P PL-H 1 60-120 PL-H 85W 0.98 150/150 75 46 92875730
HF-P PL-H 1 60-120 PL-H 120W 0.99 150/150 75 46 92875730
1 ) lp-lp = between lamp wires Typical wire capacitance 50 pF/m (spacing between wires 0.5 mm)
lp-lgnd = between lamp wires and ground Typical wire capacitance 72 pF/m (spacing between wires 0.5 mm)
2 ) Tolerance ± 3kHz
As one of the few lighting companies to manufacture both lamps and gear,
Philips has used its in-depth knowledge to develop a MASTER PL-H system
with an assured long life, one that’s fine-tuned for optimised performance.
