Lighting Systems
LP-24
1BHFPG
-JOFBS1FSG-ZUFÜ4FNJ1FSGPSBUFE-JHIU51FS'PPU /PNJOBM4FDUJPO
Mounting Accessories
Power Feed End Set
Standard Cable Length is 36” (91.44cm)
Straight Cord: LP3EC36
4 Wire Cord*: LP3EC36X4
Cable/Joiner Assembly
Standard Cable Length is 36” (91.44cm)
Single Cable: LP3C36
Single Cable & Cord: LP3CC36
Single Cable & 4 Wire Cord: LP3CC36X4
Fixture Lengths & Mounting Locations
Ceiling Grid Kit CGK
Includes both Standard 1” (2.54cm)
Tee Bar Clip & Slot Tee Clip
* use for dimming and/or emergency battery packs
4’
8’
48” (121.92cm)
4’ 2” (127.00cm)
96” (243.84cm)
8’ 2” (248.92cm)
12’
16’
20’
24’
144” (366.62cm)
12’ 2” (370.84cm)
96” (243.84cm)
16’ 2” (492.76cm)
96” (243.84cm)
144” (366.62cm)
96” (243.84cm)
20’ 2” (614.68cm)
144” (366.62cm)
144” (366.62cm)
24’ 2” (736.60cm)
Performance
CANDLEPOWER
ZONE 0
22
45
67
90
DEG.
CANDELAS
180
1272
1272
1272
1272
1272
175
1292
1259
1217
1248
1181
165
1216
1190
1201
1193
1210
155
1139
1142
1138
1151
1170
145
993
1020
1050
1085
1119
135
848
905
955
1010
1034
125
695
724
826
902
935
115
485
555
680
729
735
105
276
373
475
541
569
95
69
156
175
183
180
90
14
30
32
40
36
85
15
16
26
31
34
75
30
27
32
45
46
65
44
53
50
53
56
55
52
59
68
73
73
45
76
77
85
87
91
35
96
95
95
98
103
25
97
108
105
109
105
15
113
114
109
109
117
5
118
124
127
104
115
0
148
148
148
148
148
1200
900
600
300
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
REPORT NO: LP3B2T8.ies
LAMPS: 2-F32T8
LUMENS: 2900
EFFICIENCY: 83.0%
CAT. NO.: LP3B2T84U
ROOM CA
VITY RA
TIO
CANDLEPOWER CURVE
DISTRIBUTION
Zone
Lumens
% Lamp
% Luminaire
0-90
396
7.0
8.0
90-180
4417
76.0
92.0
0-180
4813
83.0
100.0
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80
70
50
50
30
10
50
30
10
50
30
10
0
80
80
80
70
70
70
50
50
50
1
70
67
64
60
58
56
43
42
40
2
61
56
52
53
49
45
38
35
33
3
53
47
43
46
42
38
33
30
28
4
47
41
36
41
36
32
26
26
23
5
41
35
31
36
31
27
26
22
20
6
37
31
26
32
27
23
23
20
17
7
33
27
23
29
24
20
21
17
15
8
30
24
20
26
21
17
19
15
13
9
27
21
17
23
19
15
17
14
11
10 24
19
15
21
17
13
15
12
10
20% FLOOR CAVITY REFLECTANCE
% WALL REFLECTANCE
4-Foot
Module
8-Foot
Module
12-Foot
Module
End Set
Cable/
Joiner
4-Foot Run
1
1
8-Foot Run
1
1
12-Foot Run
1
1
16-Foot Run
2
1
1
20'-Foot Run
1
1
1
1
24'-Foot Run
2
1
1
