Addendum a, Planar softkey use, Softkey install guide – Planar LX1200TI User Manual
Page 27
LX1200TI User’s Guide (020-0512-02A)
27
Addendum A
Planar Softkey Use
The Planar LX1200TI has built in programmable function buttons. This docu-
ment is to guide the user on the use and installation of the softkey software.
The Function buttons are mapped out of the box as:
BUTTON
INITIAL KEY
MAPPING
DEFAULT SOFTKEY
MAPPING
POSSIBLE KEY
MAPPING
E
F18
F11
Alt+F11
1
F13
F1
Launch Program
2
F14
F2
Ctnl+Alt+2
3
F15
F3
Past Text
4
F16
F4
Launch IE7 to an address
5
F17
F5
Open a Folder
The Planar softkey software will allow the user to remap those keys to any
other single keys, combination of keys, or launch a program from the buttons
on the front of the LX1200TI monitor.
Softkey Install Guide
1. Install the Planar Softkey software from the CD by clicking on the Planar
Softkey
Icon.
