Planar LX1200TI - Manual (Page 23)

LX1200TI User’s Guide (020-0512-02A)
23
Specifi cations
Dimensions
• Size: 313mm
(12.3”)
width x 267mm
(10.5”)
height x 46mm
(1.8”)
thickness
• Screen Size: 12.1-inch Diagonal
• Weight: 5 kg maximum
Video Specifi cations
• Input: Standard VGA (15-pin Analog)
• Resolution: XGA (1024 x 768), supports SVGA (800 x 600) and VGA
(640 x 480)
• Response Time: <35 ms (typical)
• Viewing Angle: 140° horizontal, 45° up, 55° down (typical)
• Brightness: 315 cd/m 2 , transfl ective panel (typical)
• Brightness in high ambient light conditions: 1100 cd/m 2
• Contrast: >250:1 at ambient illumination level > 5 lux (typical)
• Autosync: On power-up and any change of video mode, will
automatically detect any supported video resolution and display the
image accordingly.
Electrical Specifi cations
• Power Input: 12 VDC nominal
• Power Input Voltage Range: 8 to 24 VDC, with transient protection
resident on the monitor
• Maximum Power: 25 W
• Typical Power: Less than 17 W
• Power Consumption in Power-Saving (standby) Mode: 1.0 W (typical)
• Speaker/Amplifi er Power: 2 W per speaker
