Additional information 12
77
En
Professional Calibration EQ graphical output
Display
The display shows KEY LOCK
ON when you try to make
settings.
• With the receiver in standby, press STANDBY/ON while holding down the MULTI-ROOM&SOURCE
CONTROL button to disable the key lock.
Most recent settings have been
erased. • The power cord was disconnected from the wall while adjusting this setting.
Symptom Remedy
Symptom Remedy
The EQ response displayed in the
graphical output following
calibration does not appear
entirely flat. • There are cases where the graph does not appear flat (even when selecting ALL CH ADJUST in the Auto
MCACC Setup) due to adjustments made to compensate for room characteristics to achieve optimal sound.
• Areas of the graph may appear identical (before and after) when there is little or no adjustment needed.
• The graph may appear to have shifted vertically when comparing before and after measurements.
EQ adjustments made using the
Manual MCACC setup on
page 35 do not appear to change
the graphical output.
• Despite level adjustments being made, the filters used for analysis may not display these adjustments in
the graphical output. However, these adjustments are taken this into account by the filters dedicated to
overall system calibration.
Lower frequency response
curves do not seem to have been
calibrated for
SMALL speakers.
• Low frequencies used in bass management (the subwoofer channel) will not change for speakers that
have been specified as
SMALL in the configuration, or do not output these frequencies.
• Calibration is performed, but due to your speakers’ low frequency limitations, no measurable sound is
output for display.
Graphical output data seems to
have disappeared. • If the power is switched off, the measurement data for graphical output to a PC is cleared.
Symptom Remedy
The display is dark or off. • Press DIMMER on the remote control repeatedly to select a different brightness.
After making an adjustment the
display goes off. • Press DIMMER on the remote control repeatedly to select a different brightness.
You can't get DIGITAL to display
when using the SIGNAL SELECT
button.
• Check the digital connections and make sure that the digital inputs are assigned correctly (see The Input
Setup menu on page 61).
• If the multichannel analog inputs are selected, select a different input source.
The Dolby/DTS indicator doesn't
light when playing Dolby/DTS
software. • These indicators do dot light if playback is paused.
• Check the playback (especially the digital output) settings of the source component.
When playing a DVD-Audio disc,
the DVD player display shows
96 kHz . However, the receiver’s
display does not.
• This is not a malfunction. 96 kHz audio from DVD-Audio discs is only output from the analog outputs of
the DVD player. This receiver cannot show the playback sample rate when using the analog inputs.
During playback of a DTS 96/24
source, the display doesn't show
96kHz .
• Make sure that the receiver is set to AUTO or DIGITAL (see Choosing the input signal on page 28).
When playing Dolby Digital or
DTS sources, the receiver’s
format indicators do not light. • Check that the player is connected using a digital connection.
• Make sure that the receiver is set to
AUTO or DIGITAL (see Choosing the input signal on page 28).
• Check that the player isn’t set up so that Dolby Digital and DTS sources are converted to PCM.
• Ensure that if there are several audio tracks on the disc, the Dolby Digital or DTS is selected.
When playing certain discs, none
of the receiver’s format
indicators light. • The disc may not contain 5.1/6.1 channel material. Check the disc packaging for more on what audio
tracks are recorded on the disc.
When playing a disc, the
2 PL II or Neo:6 indicator lights
on the receiver.
• Make sure that the receiver is set to AUTO or DIGITAL (see Choosing the input signal on page 28).
• If a two channel soundtrack is currently playing (including Dolby Surround encoded), then this is not a
malfunction. Check the disc packaging for details about the audio tracks available.
