6
English
Top and front panels
1 LIFT TO OPEN – opens/ closes the CD
door
2 Source selector: CD, MW, FM,
TAPE/ OFF
– selects CD source of sound, tuner
waveband or tape source of sound
– power on/ off switch
3 CASSETTE RECORDER:
PAUSE
; – pauses recording or playback
STOP•OPEN 9/ – stops the tape; opens
the cassette door
SEARCH 5 or 6 – fast rewinds / winds
the tape
PLAY 1 – starts playback
RECORD
0 – starts recording
4 CD display – shows the CD functions
5 TUNING
6 PLAY•PAUSE 2; – starts or pauses CD
playback
7 STOP 9 – stops CD playback
8 SEARCH
∞ , §
CD: skips or searches a passage/track
backwards or forward
9 DBB (Dynamic Bass Boost) –
enhances bass response
10 REPEAT – repeats a track/CD
11 SHUFFLE – plays all CD tracks in
random order
12 VOLUME – adjusts volume level
Back Panel
13 Telescopic aerial – to improve FM
reception
14 Battery door – open to insert 6 x 1.5V
R14/UM2/ C-cell batteries
15 AC MAINS – inlet for mains lead
Power Supply
Whenever convenient, use the power
supply if you want to conserve battery life.
Make sure you remove the plug from the
set and wall socket before inserting
batteries.
For users in the U.K.: please follow the
instructions on page 2.
Batteries (not included)
1 Open the battery compartment and insert
six batteries, type R-14, UM-2 or C-cells,
(preferably alkaline) with the correct
polarity as indicated by the "+" and "–"
symbols inside the compartment.
2 Close the compartment door, and make
sure the batteries are firmly and correctly in
place.The set is now ready to operate.
Batteries contain chemical substances,
so they should be disposed of properly.
Controls Power Supply
AC M AINS ~
6 x 1.5V R14/ UM2/ C CELL
