Chapter 3 Cabling Information
You need to read
this chapter if you
want to... You need to read this chapter if you want cabling information for the SPEED LE and SPEED
LE Express serial adaptor cards.
This chapter provides cabling and connector pinout information for the SPEED LE and
SPEED LE Express serial adaptor cards. Included are details of standard cables for use with
SPEED LE and SPEED LE Express products available from Perle.
This chapter includes the following sections:
• Definitions of Signals and Direction on page 32
• Host Card Back Panel Connectors and Pinouts on page 34
• Connector Box and Cable Guide on page 43
• Connector Box and Cable Pinouts on page 44
• Low Profile Bracket Conversion on page 52
