Host Card Back Panel Connectors and Pinouts
Page 41
13
DCD5
14
RTS5
15
RI5
16
CTS5
17
RXD5
18
RXD3
19
CTS3
20
RI3
21
RTS3
22
DCD3
23
DTR3
24
DSR3
25
TXD3
26
S-GND
27
TXD1
28
DSR1
29
DTR1
30
DCD1
31
RTS1
32
RI1
33
CTS1
34
RXD1
35
RXD8
36
CTS8
37
RI8
38
RTS8
39
DCD8
40
DTR8
41
DSR8
42
TXD8
43
S-GND
VHDCI-68 Ultra
SCSI Pin
Number
EIA-232
