16 Technical data
16.1 Center
Technical data 83
ENGLISH
Specifications and external appearance are subject to change without notice.
General
AC Power
230V ±10%
Dimensions (w x h x d) 616x272x172mm
Weight (Net)
approx. 8.8kg
Power consumption
Active
<45W
Standby < 22W
Eco Power Standby < 1W
Amplifier
Output power
2x20+40W(RMS)
Frequency response 60-20,000Hz, - 3dB
Signal-to-noise ratio 72 dBA (IEC)
Speakers
Tweeter
Power
20W RMS / 30 W
music
Frequency response 5 KHz - 20 KHz
Sensitivity
76 dB / m / W
Impedance 6 Ω (Ohms)
Dimensions (w x h) 72 x 42 mm
M idrange
Power 20W RMS / 30 W
music
Frequency response 130 Hz - 5 KHz
Sensitivity
76 dB / m / W
Impedance 6 Ω (Ohms)
Dimensions (w x h) 75 x 75 mm
Subwoofer
Power
50W RMS / 75 W
music
Frequency response 75Hz - 500 Hz
Sensitivity
83dB / m / W
Impedance 12 Ω (Ohms)
Dimensions (Ø) 125mm
Headphones
Impedance
16-150 Ω (Ohms)
Input sensitivity
AUX IN
500mV
Wireless
Wireless standard
802.11g, backwards
compatible to 802.11b
Wireless security WEP (64 or 128
bit),WPA/WPA2 (8-63
characters)
Frequency range 2412-2462MHz (CH1-
CH11)
Wired (LAN / Ethernet)
Wired standard
802.3 / 802.3u
Speed 10 / 100MBit/s
Mode half / full duplex
Crossover detection (Auto MDIX)
Yes
Tuner
FM wave range
87.5-108MHz
Number of presets 60
FM antenna/cable COAX / Dipole-antenna
(75W IEC-connector)
HD player
Frequency range
60-20,000Hz, -3dB
Signal-to-noise ratio 72dBA (IEC)
MPEG 1 Layer 3 (MP3-CD)
MPEG AUDIO
MP3-CD bit rate 32-320kbps,VBR
WMA bit rate up to 160kbps
Sampling frequencies 32, 44.1, 48kHz
HD storage capacity 80GB*
Recording quality 128, or 160, or 192, or
256, or 320kbps
Recording speed 1x, 4x
CDDB (CD recognition database)
internal Gracenote® /
online access enabled
* Actual formatted capacity will be less
USB player
USB
12Mb/s,V1.1
(support MP3,WMA and
M4A files)
USB class MSC, MTP
Number of tracks/titles maximum 9999
