33
Main Menu
(continued)
Underlined values indicate factory defaults.
*1 Available during HD-SDI input signals.
*2 Available during VIDEO (NTSC) input. Closed captions appear as bright lines on line 21 when closed caption is
set to ON and underscan is also on.
*3 Opens the vector display during SDI signal input.
DISPLAY SETUP
Sub menu Settings Description
WFM/
VECTOR
OFF
WFM
VECTOR Switches between “WFM/VECTOR” waveform and vector display.
Displays
waveforms.
Displays vector waveforms.
*3
POSITION LB
RB
RT
LT Selects the position for the “WFM/VECTOR” waveform display.
*3
Left Bottom
Right Bottom
Right Top
Left Top
VECTOR
MODE
Ч 8
Ч 4
Ч 2
Ч 1 Enlarges vector waveforms.
*3
<× 8> 8×
<× 4> 4×
<× 2> 2×
<× 1> 1×
VECTOR
SCALE 100%
75% Determines the scale of vector waveform.
<100%>
Displays it at 100% scale.
<75%> Displays it at 75% scale.
TIME CODE OFF
ON
Turns the time code display on and off.
*1
MODE
SELECT LTC
VITC
LUB
VUB Selects time code display mode.
*1
Displays linear time code (LTC).
Displays vertical interval time code (VITC).
Displays user bits included in LTC.
Displays user bits included in VITC.
CLOSED
CAPTION OFF
ON
Turns closed caption display on and off.
*2
MODE
SELECT CC4
CC3
CC2
CC1
Selects the cross caption display mode.
*2
