background image

18

Underlined values indicate factory defaults.

*1 This setting is turned “ON” when receiving marker control in REMOTE operation. (GPI, if set, has priority.)
*2 These settings are disabled when the GPI function (

J page 36) is used to control the marker setting.

They are also disabled in split screen mode.

*3 This setting is enabled only for HD and SD signal input in 16:9 aspect ratio mode.
*4 This setting is enabled for SD signal input in 4:3 aspect ratio mode.
*5 Remote control via RS-232C ends in error (error response: ER001) when “GPI PRESET1” or “GPI PRESET2”

is selected with the GPI function.

*6 Display size for SD signals differ.

TYPE1: The effective horizontal area meets the SMPTE125M for NTSC and ITU-R BT 601-5 for PAL.
TYPE2: The effective horizontal area meets the EIA-RS170 for NTSC and ITU-R BT 470-4 for PAL.

MARKER

Sub menu

Setting

Description

MARKER

OFF

*1

ON

Enables the MARKER setting.

16:9

*2*3

OFF
4:3
13:9
14:9
CNSCO
VISTA
95%
93%
90%
88%
80%

Selects and displays marker type for 16:9 aspect ratio.

No marker display

<4:3>

4:3 marker

<13:9>

13:9 marker

<14:9>

14:9 marker

CNSCO marker

VISTA marker

<95%>

95% area marker

<90%>

90% area marker

<80%>

80% area marker

<93%>

93.1% area marker (TYPE1)
93% area marker (TYPE2)

<88%>

89.5% area marker (TYPE1)
88% area marker (TYPE2)

4:3

*2*4

OFF
95%
93%
90%
88%
80%

Selects and displays marker type for 4:3 aspect ratio.

No marker display

<95%>

95% area marker

<93%>

93% area marker

<90%>

90% area marker

<80%>

80% area marker

<88%>

89% area marker (TYPE1)
88% area marker (TYPE2)

BACK

*2

NORMAL
HALF
BLACK

Selects the background brightness around the marker.

Normal background

50% background brightness

0% background brightness (black)

CENTER

*2

OFF
ON

Displays the center marker.

Turns the display off

Turns the display on

GPI PRESET1

*5

4:3
13:9
14:9
CNSCO
VISTA
95% (16:9)
93% (16:9)
90% (16:9)
88% (16:9)
80% (16:9)
95% (4:3)
93% (4:3)
90% (4:3)
88% (4:3)
80% (4:3)

GPI PRESET1: Selects the marker displayed by the GPI terminal
“MARKER1 ON/OFF” (

J page 36) operation.

GPI PRESET2: Selects the marker displayed by the GPI terminal
“MARKER2 ON/OFF” (

J page 36) operation.

<4:3>

4:3 marker

<13:9>

13:9 marker

<14:9>

14:9 marker

CNSCO marker

VISTA marker

<95% (16:9)> 95% area marker for 16:9 aspect ratio
<93% (16:9)> 93% area marker for 16:9 aspect ratio
<90% (16:9)> 90% area marker for 16:9 aspect ratio
<88% (16:9)> 88% area marker for 16:9 aspect ratio
<80% (16:9)> 80% area marker for 16:9 aspect ratio
<95% (4:3)>

95% area marker for 4:3 aspect ratio

<93% (4:3)>

93% area marker for 4:3 aspect ratio

<90% (4:3)>

90% area marker for 4:3 aspect ratio

<88% (4:3)>

88% area marker for 4:3 aspect ratio

<80% (4:3)>

80% area marker for 4:3 aspect ratio

GPI PRESET2

*5

MARKER TYPE

*6

TYPE1
TYPE2

Selects conventional monitor or camera recorder marker size.

Conventional monitor marker size

Marker size compliant with the camera recorder (Panasonic)

CROSS HATCH

HIGH
LOW
OFF

Turns the cross hatch grid on and off and sets its density.

70/256 (displays a dense cross hatch grid)

20/256 (displays a light cross hatch grid)

Turns the display off

Main Menu

(continued)
