Connect audio/video cables
Note
Match the color of the AV cable with the jacks: the yellow
cable is for the yellow video jack, the red/white cable is for
the red/white audio jacks.
•
1
Connect AV cable to the main unit and to
the screen.
Connect power
Caution
Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back or
the underside of the player.
Risk of electric shock! When you unplug the AC adaptor,
always pull the plug from the socket. Never pull the cord.
•
•
1
Connect the single-connector end of the
power cord to the DC OUT jack of the
main unit.
2
Connect one end of the double-connector
end of the power cord to the DC IN jack of
one screen.
3
Repeat step 2 with the other screen.
4
Connect the power:
