VEHICLE TECHNICAL DATA

Chassis

Tubular and sheet steel

Front suspension

The tilt mechanism is composed of
an articulated parallelogram
suspension with die-cast
aluminium control arms and two
side headstocks plus shock
absorbers with hydraulic locking
system.

Rear suspension

Two double-acting shock
absorbers, adjustable to four
positions at preloading.

Front brake

Ø 240 mm double disk with
hydraulic control activated by the
handlebar right-hand lever.

Rear brake

disc brake, diameter 240 mm, with
hydraulic servo operated from the
handlebar with the left-hand lever.

Wheel rim type

Light alloy rims.

Front rim

12'' x 3.00

Rear rim

14'' x 4.50

Front tyre

Tubeless 120/70-12" 51S or 51P

Rear tyre

Tubeless 140/70 - 14" 68S or 68P
reinf

Front tyre pressure (with
passenger)

1.6 bar (1.8 bar)

Rear tyre pressure (with
passenger)

2.4 bar (2.6 bar)

82

4 Technical data
