Rear tyre Tubeless 140/70 - 14" 68S or 68P
reinf
TYRE INFLATION PRESSURE
Front tyre pressure (with
passenger) 1.6 bar (1.8 bar)
Rear tyre pressure (with
passenger) 2.4 bar (2.6 bar)
02_04
02_05
Shock absorbers adjustment (02_04, 02_05)
The preloading of the springs can be adjusted to 4 positions using the ring nut located
in the lower part of the shock absorbers and the specific spanner supplied.
Position 1: Minimum preload: driver only
Position 2 medium preloading: driver only
Position 3 medium preloading: rider and passenger
Position 4: Maximum preload: driver, passenger, and luggage.
In order to carry out this operation you will need to use the specific spanner in the kit.
CAUTION
RIDING THE VEHICLE WITH THE SPRING PRELOADING NOT CORRECTLY SET
FOR THE RIDER AND POSSIBLE PASSENGER, COULD REDUCE THE COM-
FORT OF THE RIDE AND THE PRECISION OF THE STEERING.
