Initial Setup
Rear View of the unit
Connections
For ANT./Cable
Connect the cable from
Antenna/Cable to the VHF/UHF
terminal on the unit.
For DSS/Cable Box
Connect the OUT jack on your
cable box to the VHF/UHF
terminal on the unit with a RF
cable.
Overtightening “Nut type” RF coaxial cables
may damage jacks. Finger tighten only.
WARNING
AC Power Plug
When plugged into an AC
outlet, this unit consumes
3.5 W of electric power in
OFF condition.
VHF/UHF Antenna
Input Terminal
See below.
Audio/Video Input
Connector 1 (LINE 1)
Connect from other
component.
Optical digital audio
output connector
Pg. 12
S-Video Input
Connector 1 (LINE 1)
Connect from other
component with S-Video.
Audio Output
Connector (L/R)
Pg. 12
IN from
ANT./CABLE
VHF/UHF
VHF/UHF
VHF/UHF
VHF/UHF
Cable TV
Converter Box
IN from
ANT./CABLE
