Philips Semiconductors Linear Products
Product specification
µ
A733/733C
Differential video amplifier
April 15, 1992
263
ABSOLUTE MAXIMUM RATINGS
SYMBOL
PARAMETER
RATING
UNIT
V
DIFF
Differential input voltage
±
5
V
V
CM
Common-mode input voltage
±
6
V
V
CC
Supply voltage
±
8
V
I
OUT
Output current
10
mA
T
J
Junction temperature
+150
°
C
T
STG
Storage temperature range
-65 to +150
°
C
T
A
Operating ambient temperature range
µ
A733C
0 to +70
°
C
µ
A733
-55 to +125
°
C
P
D MAX
Maximum power dissipation,
1420
mW
25
°
C ambient temperature (still-air)
1
NOTE:
1. The following derating factors should be applied above 25
°
C:
N package at 11.4mW/
°
C
DC ELECTRICAL CHARACTERISTICS
T
A
=+25
°
C, V
S
=
±
6V, V
CM
=0, unless otherwisespecified. Recommended operating supply voltages V
S
=
±
6.0V.
SYMBOL
PARAMETER
TEST CONDITIONS
µ
A733C
µ
A733
UNIT
SYMBOL
PARAMETER
TEST CONDITIONS
Min
Typ
Max
Min
Typ
Max
UNIT
Differential voltage gain
R
I
= 2k
Ω
, V
OUT
= 3V
P-P
Gain 1
2
250
400
600
300
400
500
V/V
Gain 2
2
80
100
120
90
100
110
V/V
Gain 3
3
8
10
12
9
10
11
V/V
BW
Gain 1
1
40
40
MHz
BW
Gain 2
2
90
90
MHz
Gain 3
3
120
120
t
R
V
OUT
= 1V
P-P
Gain 1
1
10.5
10.5
ns
Gain 2
2
4.5
12
4.5
10
ns
Gain 3
3
2.5
2.5
ns
t
PD
V
OUT
= 1V
P-P
Gain 1
1
7.5
7.5
ns
Gain 2
2
6.0
10
6.0
10
ns
Gain 3
3
3.6
3.6
ns
R
IN
Gain 1
2
4.0
4.0
k
Ω
Gain 2
2
10
30
20
30
k
Ω
Gain 3
3
250
250
k
Ω
Input capacitance
2
Gain 2
2.0
2.0
pF
I
OS
Input offset current
0.4
5.0
0.4
3.0
µ
A
I
BIAS
Input bias current
9.0
30
9.0
20
µ
A
V
NOISE
Input noise voltage
BW=1kHz to 10MHz
12
12
µ
V
RMS
V
IN
Input voltage range
±
1.0
±
1.0
V
CMRR
Gain 2
V
CM
=
±
1V, f
≤
100kHz
60
86
60
86
dB
Gain 2
V
CM
=
±
1V, f=5MHz
60
60
dB
