Controls on the system and
remote control

1 STANDBY ON
–

to switch the system on or to standby
mode.

–

to use for EASY SET.

2 PROGRAM

for CD ............ to program CD tracks.
for TUNER ..... to program preset radio

stations.

for CLOCK ..... to select 12- or 24-

hour in clock setting
mode.

3 DIGITAL SOUND CONTROL

DISPLAY PANEL

–

to view the desired DSC display.

4 JOG CONTROL/DSC
–

to select the desired equalizer display:
OPTIMAL, JAZZ, ROCK or TECHNO.

5 DBB (DYNAMIC BASS BOOST)
–

to switch on bass boost to enhance
bass response or to switch off bass
boost.

6 DISPLAY SCREEN
–

to view the current setting of the
system.

7 CD CAROUSEL TRAY
8 DISC CHANGE
–

to change CD(s).

9 OPEN•CLOSE
–

to open or close the CD carousel tray.

0 DISC 1 / DISC 2 / DISC 3 (CD

DIRECT PLAY)

–

to select a CD tray for playback.

! SOURCE – to select the following:

CD / (CD 1•2•3)

–

to select CD mode. When CD playback
is stopped, press to select disc tray 1,
2 or 3.
TUNER / (BAND)

–

to select Tuner mode. When in tuner
mode, press to select the waveband:
FM or MW.
TAPE / (TAPE 1• 2)

–

to select Tape mode.
AUX / (VIDEO)

–

to select sound from an external
source (e.g. TV, VCR, Laser Disc player,
DVD player or CD Recorder).

@ MODE SELECTION

SEARCH а б (TUNING а б)
for CD ............ to search backward/

forward.

for TUNER ...... to tune to a lower or

higher radio frequency.

for CLOCK ..... to set the hour

(on the

system only) .

STOP•CLEAR Ç
for CD ............ to stop CD playback or

to clear a program.

for TUNER ..... to stop programming.
for DEMO ......

(on the system only) to
start or stop
demonstration mode.

PLAY É / PAUSE Å
for CD ............ to start or interrupt

playback.

PREV í / NEXT ë(PRESET

43 )

for CD ............ to skip to the beginning

of the current, previous,
or next track.

for TUNER ..... to select a preset

station in memory.

for CLOCK ..... to set the minute

(on

the system only).

# VOLUME
–

to increase or decrease the volume.

$ n
–

to connect headphones.

% DIM
–

to select different brightness for the
display screen : DIM 1, DIM 2, DIM 3
or DIM OFF.

^ CLOCK•TIMER
–

to view the clock, set the clock or set
the timer.

& TAPE DECK 2
* TAPE DECK 2 OPERATION

PLAYÉ ....... to start playback.
à ................. to rewind the tape.
á ................. to fast forward the

tape.

STOP•OPEN…to stop playback or to

open the tape door.

PAUSE ......... to interrupt playback.

( TAPE DECK 1 OPERATION

RECORD ....... to start recording.
PLAYÉ ....... to start playback.
à ................. to rewind the tape.
á ................. to fast forward the

tape.

STOP•OPEN…to stop playback/

recording or to open the
tape door.

PAUSE ......... to interrupt playback or

recording.

) TAPE DECK 1
¡ MIC LEVEL (not available for version

/30)

–

to adjust the mixing level for karaoke
or microphone recording.

™ MICROPHONE (not available for

version /30)

–

to connect microphones jack.

£ REPEAT
–

to repeat a CD track, a disc, or all
available discs.

≤ MUTE
–

to switch off the sound temporarily.

∞ SHUFFLE
–

to play all the available discs and their
tracks in random order.

§ SLEEP
–

to switch the system to standby mode
at a selected time.

≥ B
–

to switch the system to standby mode.

CONTROLS

Notes for remote control:
– First select the source you wish to

control by pressing one of the
source select keys on the remote
control (e.g. CD ,TUNER, etc.).

– Then select the desired function

(Й, н, л, etc.).
