Jiva SL & Jiva EL (TP5700/5800) USER’S MANUAL 4 - 3
Switch Manager” in “Posiflex Tools” in the Program Files helps managing these
functions.
Software Support
The Jiva series provides a software power off command for application
program maneuvers. The Jiva also provides a specific means for the software to detect
if the system is working on external or UPS battery power. Due to this feature,
compatible software applications have the ability to change operating conditions when
running on standard/backup power. The software programmer may take reference
from the Jiva technical manual to apply such features.
DISPLAY RESOLUTION
For best viewing result please set your display resolution of TP5X12 at 800 x
600 with high color in the operation system. For TP5X15, please set the display
resolution at 1024 x 768 with high color.
In configuration of system memory, max. 64 MB can be shared as the video
memory.
External LCD Monitor
The external VGA port in the Jiva SL & Jiva EL series supports LM6000/6001
LCD monitor. This port supports either mirror mode (identical image) or extended
mode dual display function. To support the DC powered Posiflex LCD monitor, an
internal jumper must be set to supply the required power through the connector.
SECURITY DEVICES
Please follow the instructions on the manual that comes along with the security
devices SD100 or KP100 when it is installed.
SERIAL PORTS – COM1/2/3/4
In Jiva SL & Jiva EL series, there are 4 serial ports available except those
models using RS232 touch interface. All the serial ports can supply a +5 V DC
