10
IMAGE ADJUST MENU
The Image Adjust Menu is shown below.
IMAGE ADJUST
AUTO TUNE
H. / V. POSITION
H. SIZE
PHASE
ZOOM
: EXIT A : SELECT B
AUTO – TUNE
automatically sizes, enters, and fine-tunes the video signal to
eliminate noise and distortion.
Press [ B ] button to activate Auto-tune.
H POSITION
(Horizontal Position) moves the screen image to the left or to the right.
[
▽
] button moves the screen image to the left,
[
△
] button moves the screen image to the right.
V POSITION
(Vertical Position) moves the screen image up or down.
[
▽
] button moves the screen image down, [
△
] button moves the screen image up.
H. / V. Position Diagram
: V. POSITION
H. POSITION
USE UP AND DOWN TO ADJUST
= =
: EXIT A B
V. POSITION
: ZOOM
USE UP AND DOWN TO ADJUST
= =
A : H. POSITION B
