Philips Semiconductors

Product specification

PTN3501

Maintenance and control device

2

2001 Jan 17

853-2227 25436

FEATURES

I

2

C to parallel port expander

Internal 256x8 E

2

PROM

Self timed write cycle (5 ms typ.)

16 byte page write operation

Controlled pull-up on address lines

Low voltage V

CC

range of +2.5 V to +3.6 V

5 V – tolerant I/Os

Low standby current (< 60

µ

A )

Power on Reset

Supports Live Insertion

Compatible with SMBus specification version 1.1

High E

2

PROM endurance and data retention

Available in TSSOP20 package

DESCRIPTION

The PTN3501 is a general purpose maintenance and control device.
It features an on-board E

2

PROM that can be used to store error

codes or board manufacturing data for read–back by application
software for diagnostic purposes.

The eight quasi bidirectional data pins can be independently
assigned as inputs or outputs to monitor board level status or
activate indicator devices such as LEDs.

The PTN3501 has six address pins allowing up to 64 devices to
share the common two wire I

2

C software protocol serial data bus.

The PTN3501 supports live insertion to facilitate usage in removable
cards on backplane systems.

The PTN3501 is an alternative to the functionally similar PTN3500
for systems where a high number of devices are required to share
the same I

2

C-bus without need for an additional I

2

C-bus I/O

expander.

PIN CONFIGURATION

1

2

3

4

5

6

7

20

19

18

17

16

15

14

A0

A1

A2

P0

P1

P2

P3

SDA

SCL

P7

P6

P5

WC

V

DD

SW00657

PTN3501

8

13

P4

9

10

12

11

A5

A3

A4

V

SS

INT

Figure 1.

PIN DESCRIPTION

PIN NUMBER

SYMBOL

NAME AND FUNCTION

1,2,3,9,11,12

A0:5

Address Lines

4,5,6,7

P0:3

Quasi–bidirectional I/O pins

10

V

SS

Ground

13,14,15,16

P4:7

Quasi–bidirectional I/O pins

17

WC

Write Control Pin. Should be
tied LOW.

8

INT

Interrupt Pin

18

SCL

I

2

C Serial Clock

19

SDA

I

2

C Serial Data

20

V

DD

Supply Voltage

ORDERING INFORMATION

Type n mber

Package

Type number

Name

Description

Version

PTN3501DH

TSSOP20

Plastic thin shrink small-outline package; 20 leads; body width 4.4 mm

SOT360-1

FUNCTIONAL DIAGRAM

I

2

C

CONTROL

8-BIT

I/O PORT

P7:0

A5:0

SDA

SCL

E2PROM

256

×

8

WC

INT

SW00647

Figure 2.
