Philips Semiconductors

Product specification

PTN3501

Maintenance and control device

2001 Jan 17

10

ABSOLUTE MAXIMUM RATINGS

Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these conditions is not implied.

SYMBOL

PARAMETER

MIN

MAX

UNIT

V

CC

Supply Voltage

–0.5

4.0

V

V

I

Input Voltage

V

SS

– 0.5

5.5

V

I

I

DC Input Current

–20

20

mA

I

O

DC Output Current

–25

25

mA

I

DD

Supply Current

–100

100

mA

I

SS

Supply Current

–100

100

mA

P

tot

Total Power Dissipation

400

mW

P

O

Total Power Dissipation per Output

100

mW

T

STG

Storage Temperature

–65

+150

_

C

T

AMB

Operating Temperature

–40

+85

_

C

V

ESD

Electrostatic Discharge:

Human Body Model, 1.5 k

, 100 pF

>2000

V

Machine Model, 0

, 200 pF

>200

V

DC ELECTRICAL CHARACTERISTICS

T

amb

= –40

_

C to +85

_

C unless otherwise specified; V

CC

= 3.3 V

SYMBOL

PARAMETER

MIN

TYP

MAX

UNIT

Supply

V

DD

Supply Voltage

2.5

3.3

3.6

V

I

DDQ

Standby Current; A

0

thru A

5

, WC = HIGH

60

µ

A

I

DD1

Supply Current Read

1

mA

I

DD2

Supply Current Write

2

mA

V

POR

Power on Reset Voltage

2.4

V

Input SCL; input, output SDA

V

IL

Input LOW voltage

–0.5

0.3 V

DD

V

V

IH

Input HIGH voltage

0.7 V

DD

5.5

V

I

OL

Output LOW current @ V

OL

= 0.4 V

3

mA

I

L

Input leakage current @ V

I

= V

DD

or V

SS

–1

1

µ

A

C

I

Input capacitance @ V

I

= V

SS

7

pF

I/O Expander Port

V

IL

Input LOW voltage

–0.5

0.3 V

DD

V

V

IH

Input HIGH voltage

0.7 V

DD

5.5

V

I

IHL(max)

Input current through protection diodes

–400

400

µ

A

I

OL

Output LOW current @ V

OL

= 1 V

10

25

mA

I

OH

Output HIGH current @ V

OH

= V

ss

30

100

300

µ

A

I

OHt

Transient pull–up current

2

mA

C

I

Input Capacitance

10

pF

C

O

Output Capacitance

10

pF

Address Inputs A

0

thru A

5

, WC input

V

IL

Input LOW voltage

–0.5

0.3 V

DD

V

V

IH

Input HIGH voltage

0.7 V

DD

5.5

V

I

L

Input leakage current @ V

I

= V

DD

–1

1

µ

A

Input leakage (pull-up) current @ V

I

= V

SS

10

25

100

µ

A

Interrupt output INT

I

OL

Low level output current; V

OL

= 0.4 V

1.6

mA

I

L

Leakage current @ V

I

= V

DD

or V

SS

–1

+1

µ

A
