Planet Technology 85M Powerline Ethernet PL-201-UK/US User Manual
Page 7
LED definition
LED Description
PWR
Steady on indicate the powerline device connect to the
power outlet
Steady on indicates the RJ-45 port has correctly
connected to the network card of your PC or the Ethernet
network
ETH
Blinking indicates the data are transferring
Steady on indicates there exists another powerline device
PL
Blinking indicates the data are transferring
Wire Diagram
7
