Patton electronic 470 Series User Manual
User manual, Model 470 series, Atm coax to twisted pair adapters (baluns)
USER
MANUAL
MODEL 470 Series
ATM Coax to Twisted Pair
Adapters (Baluns)
SALES OFFICE
(301) 975-1000
TECHNICAL SUPPORT
(301) 975-1007
http://www.patton.com
Part #07M470-A
Doc. #019091UA
Revised 9/11/98
PATTON MODEL 470 SERIES SPECIFICATIONS
Tranmission Medium: 155.52 Mbps ATM over Twisted Pair
75 Ohm Connection: Dual BNC Coax Connectors (female, 75
Ohm)
Power Supply None Required
Dimensions:
Model 470: 100 Ohm CAT-5 single 8-pin RJ-45 Jack,
Shielded
Model 471: 120 Ohm CAT-5 Single 8-pin RJ-45 Jack,
Shielded
Model 472: 150 Ohm IBM Data Connector, 2 Twisted
Pair, Shielded
3
An ISO-9001
Certified Company
