Panasonic WV-C L924A - Manual (Page 40)

-41-
To reset to the factory settings
1. Move the cursor to the CAMERA RESET parameter.
PUSH SW is highlighted.
2. While holding down
L and M, press I for 2
seconds or more. The camera is reset to the factory
settings.
** SPECIAL **
UP SIDE DOWN OFF
CHROMA GAIN ....I....
AP GAIN ....I....
PEDESTAL ....I....
HUE ....I....
- +
BW OFF
BURST (BW) ON
CAMERA RESET PUSH SW
RET END
5. Move the cursor to LEVEL and select the illumi-
nance level using
L or M.
LOW: Color picture switches to black-and-white at
approx.1 lx with F1.4 lens.
HIGH: Color picture switches to black-and-white at
approx.5 lx with F1.4 lens.
The factory default setting is HIGH.
6. Move the cursor to DURATION TIME to set the
switching time using L or M.
The following switching times are available:
10s--30s--60s--300s
(S)
(L)
10-7. BURST (BW)
1. Move the cursor to the BURST (BW) parameter.
2. Select ON or OFF using
L or M.
Default: ON
ON: The burst signal is supplied along with the
black and white composite video signal.
OFF: The burst signal is not output.
Note: Select the appropriate mode for the con-
nected recording device and monitor TV
when setting BW (10-6) and burst signal
(10-7). There may be cases where the
selection will adversely affect synchro-
nization. Select the mode after confirming
that the live picture and playback picture
are properly displayed on the monitor.
