Patton electronic 1170M SERIES User Manual
Page 13

13
The LED indicators reflect the following operating status:
Table 2:
LED indicator descriptions
Number
Name
Description
1
PWR
Illuminates green to shown that power is applied to unit.
2
FO100
Illuminates green to show that a 100 Mbps signal is
present on the fiber optic side of the unit. (Not used
on Model 1171M.)
3
FOACT
Blinks yellow to show activity on the fiber optic side
of the unit.
4
FO10
Illuminates green to show that a 10 Mbps signal is
present on the fiber optic side of the unit. (Not used
on Model 1170M.)
5
TP100
Illuminates green to show that a 100 Mbps signal is
present on the twisted-pair/copper side of the unit.
(Not used on Model 1171M.)
6
TPACT
Blinks yellow to show activity on the twisted-pair/
copper side of the unit.
7
TP10
Illuminates green to show that a 10 Mbps signal is
present on the twisted-pair/copper side of the unit.
(Not used on Model 1170M.)
