ENGLISH
6
1
Power supply socket.
2
Digital audio output connector.
3
Audio R; Audio output R.
4
Audio L; Audio output L.
5
Video (CVBS); Video output.
6
DC Power output connector
7
Euroconnector (Europe only).
8
S-Video (USA only).
9
NTSC/PAL switch (for player menus).
CAUTION
DO NOT TOUCH THE INNER PINS OF REAR-PANEL
CONNECTORS. ELECTROSTATIC DISCHARGE MAY CAUSE
PERMANENT DAMAGE TO THE UNIT.
1
Remote control active (flashing).
2
FTS (Favourite Track Selection) active.
3
SHUFFLE active.
4
PAUSE active.
5
SCAN active.
6
REPEAT A-B/CHAPTER/TITLE/TRACK mode active.
7
Chapter or track calendar.
8
TOTAL/REMaining/TRACK TIME in hours, minutes and
seconds.
9 (V)CD play.
10 DVD
play.
11 DVD CHAPTER or VCD/CD TRACK number.
12 DVD TITLE number.
1
REPEAT (chapter, track,
title, disc).
2
A-B REPEAT.
3
SCAN On/Off.
4
SUBTITLE language
selector or Subtitle
On/Off.
5
SETUP; Select player
SETTINGS menu (in Stop
mode only).
6
Select DVD camera
ANGLE.
7
T-C; mode selector
Title/Chapter.
8
Numerical key pad.
9
Jog/shuttle control.
10 JOG/PAUSE (On/Off)
11 TV VOLume (Up/Down).
12 STOP 9 or EJECT.
13 PREVIOUS O /search
backward.
14 PLAY 2.
15 RETURN.
16 Cursor down 4.
17 Cursor left 1.
18 Cursor up 3.
19 TITLE; title menu
On/Off.
20 TV POWER.
21 TV /DVD selector.
22 DVD /Standby.
23 TV Audio MUTE.
24 MENU; root menu
On/Off.
25 Cursor right 2.
26 ENTER (acknowledge
menu selection).
27 NEXT P /search forward.
28 TV Preset (Up/Down).
29 OSD (On-Screen Display) on/off.
30 AUDIO language selector.
31 RESUME play from last position.
32 FTS (Favourite Track Selection).
33 SHUFFLE on/off.
+
--
+
--
+
--
+
--
TV
TITLE
RETURN
EJECT
TV VOL
TV P
JOG/PAUSE
ENTER
MENU
TV/DVD
DVD
J
K
2
9
1
2
3
4
5
6
7
8
9
0
T-C
+ j
ANGLE
SETUP
SUBTITLE AUDIO
RESUME
FTS
SHUFFLE
REPEAT
REPEAT
A-B
SCAN
....
1
2
3
4
3
5
7
8
9
11
12
14
13
15
17
19
20
4
16
6
21
18
33
32
30
31
29
27
25
24
28
22
23
26
1
10
2
REMOTE CONTROL
TRACK
TITLE
SCAN
PAUSE
TIME
TRACK
TOTAL REM
CHAPTER
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
CD
REPEAT
SHUFFLE
F S
T
CHAPTER
TITLE
TRACK
V
-B
A
.
.
.
.
.
.
.
.
.
.
.
.
.
.
+
1
3
10
4
5
2
6
7
12
11
9
8
DISPLAY
REAR OF PLAYER
20
18
16
14
12
10
8
6
4
2
19
17
15
13
11
9
7
5
3
1
21
1
2
3
4
5 6
8
9
7
INSTALLATION
