Notes:
• Surely attach a pipe fitting to the bracket to avoid exposing the cables. Otherwise, cable
deterioration resulting from cable exposure may cause a short circuit.
• Run the conduit downward or pull the conduit out of the side of the bracket. When pulling
the conduit out of the side of the bracket, run the conduit downward once, and upward.
• For wall installation, face the drain hole downward and do not block the hole. When rain
water is accumulated in the bracket, the water blocks the desiccant agent and air mem-
brane permeation on the rear of the camera, which may cause water leakage.
20
Drain hole
Pipe
