The maximum backcan dimensions
shall be no more than 197 mm (7.75 in.)
in height by 219.2 mm (8.63 in.) in diam-
eter. The maximum visible dimensions
shall be no more than 24.4 mm (0.96 in.)
in height by 271.9 mm (10.71 in.) in diam-
eter. The backcan shall be constructed of
aluminum.
The grille shall be constructed of an
ABS bezel and powder-coated steel for
lasting performance in the elements.
The affixed grille and bezel shall be
mounted to the speaker enclosure
(backcan) via neodymium magnets and
included safety leash. Also included are
a paint mask for in-field painting and
an installation aid that serves as a hand-
hold during mounting.
The system shall include a 21-gauge
galvanized steel support backing plate
(tile bridge) to reinforce the ceiling mate-
rial and tile support rails. The tile bridge
shall be color-coded (blue) to simplify
ordering and inventory tracking. The
maximum tile bridge dimensions shall
be no more than 600.1 mm (23.62 in.) in
length by 323.9 mm (12.75 in.) in width
and 11 mm (0.41 in.) in height with a 228.6
mm (9.0 in.) cutout for speaker mounting.
The CM500i has an optional color-
coded (blue) pre-construction bracket
(AC-CM5-PCB) that shall be compat-
ible with an optional junction box
(AC-CMi-JBOX). A 2-foot, 18-gauge
wire whip and Euroblock connector
shall be included with the junction box.
The maximum dimensions of the pre-
construction bracket shall be no more
than 635 mm (25.0 in.) in length by 381
mm (15.0 in.) in width and 128 mm (5.0
in.) in height (includes affixed junction
box) with a 228.6 mm (9.0 in.) cutout for
speaker mounting.
The system shall be the SoundTube
CM500i for both low- and high-imped-
ance applications.
SoundTube Entertainment
6430 North Business Park Loop
Park City, Utah 84098
Phone 435.647.9555
Fax
435.647.9666
Toll Free 800.647.TUBE
www.soundtube.com
All SoundTube products come
with a 5-year limited warranty.
