Philips SBCHD1500U User Manual

Page 15

ENGLISH

Using Your HD1500U Digital Wireless Headphone
System

To begin using your HD1500U digital wireless headphone system, start from
the left side of the base station. Follow instructions below and gradually
read from left to right of the user interface.

1 Power on your audio source.

2 (For analog connection) In case the RCA output level of your audio source

is adjustable, adjust the output to the highest acceptable undistorted level.

Note: Also, make sure the GAIN button, located at the back of the panel, under

each Analog input jack, is set to the appropriate level. For details, please
refer to the ‘Functional Overview’ section.

3 Power on the HD1500U base station.The power indication of the base

station will change from red to green.

4 The source menu light is illuminated in yellow, meaning that you could

choose the input source you would like to play.

5 Select the input source you wish to listen to by pressing the ‘source’ button.

You have a choice between:
– Analog source (ANALOG 1, ANALOG 2)
– Digital source (S/PDIF – DIGITAL1, Optical digital – DIGITAL 2)

6 Once a valid audio signal is detected, the green ‘Transmit On’ indicator lights

up. Pressing the ‘transmit’ button can disable the transmitter function.

Note: The ‘Transmit’ menu is always illuminated in yellow, indicating that the

function is always available.
