V X C ENTURY S ERIES
A PPENDIX A
Console Side Dimensions The following diagram illustrates the depth and height dimen- sions (from the side) for all Century Vx consoles.
2.25"/57mm
24.75" / 629mm
28.0" / 71
1mm
30.21"/767mm
35
°
12.6875"
322mm
12.5625"
319mm
.65"/17mm
31.14" / 791mm
DO
NOT
APPL
Y
ANY
LOADS T
O
METER
BRIDGE ASSEMBL
Y
5.125" 130mm
10
°
SUPPOR
T
ACROSS
THIS DIMENSION IS RECOMMENDED
SUPPOR
T
ACROSS
THIS AREA
IS
RECOMMENDED
KNOB HEIGHT
, .75"/19mm & 1.25"/32mm
19" / 483mm
29.5625" / 751mm
2.375"/ 60mm
1.30"/ 33mm
4.8125" 122mm
4.5625" 1
16mm
All information per
Crest Consoles Engineering,
May 5, 1997
