114
SPECIFICATIONS
* Based on EU Directive 76/432/EC
Sportsman 300
Maximum Weight Capacity 385 lbs. (175 kg) (includes weight of opera-
tor, cargo and accessories)
Dry Weight 550 lbs. (250 kg)
Fuel Capacity 4.5 gal. (17 l)
Engine Oil Capacity 2 qts. (1.9 l)
Transmission Oil 20.3 oz. (600 ml)
Demand Drive Fluid 5 oz. (148 ml)
Front Rack Capacity 70 lbs. (32 kg)
Rear Rack Capacity 100 lbs. (45 kg)
Hitch Tongue Weight Capacity 75 lbs. (34 kg) (Rear rack capacity and tongue
weight not to exceed 100 lbs./45 kg)
Hitch Towing Rating 750 lbs. (340.2 kg)
Unbraked Trailer Towing Capacity* 1213 lbs. (550 kg)
Overall Length 74 in. (188 cm)
Overall Width 42 in. (107 cm)
Overall Height 45.5 in. (116 cm)
Wheelbase 46 in. (117 cm)
Ground Clearance 8 in. (20 cm)
Minimum Turning Radius 62.5 in. (159 cm) unloaded
Engine Model Number/Type ES300PFE / 4-Cycle, Single Cylinder
Lubrication Wet sump
Engine Cooling Air
Displacement 299 cc
Bore x Stroke 78.5 x 68
Alternator Output 250 w
Compression Ratio 9.2:1
Carburetor Mikuni BST 34
Pilot Jet 45
Main Jet 140
Needle Jet 0-5M
Jet Needle 4HC57-3
Pilot Air Jet 140
Ignition System DC CDI
Ignition Timing 10
° +/- 2° @ 1500 RPM/30° +/- 2° @ 5000
RPM
Spark Plug / Gap NGK CR8E / .031 in. (0.8 mm)
Driving System Type Automatic PVT (Polaris Variable Transmis-
sion)
Shift Type Side Lever (H/N/R)
