12
20069400 Baffle Center Strap ........................ 3200/5000 .........................
20015101 Flue End Assy, Left ....................... all ......................................
20015102 Flue End Assy, Right ..................... all ......................................
20016702 Flue Panel Rear ............................. 2450I/2200E .....................
20016703 Flue Panel Rear ............................. 3050I/2800E .....................
20016704 Flue Panel Rear ............................. 3500I/3200E .....................
20016705 Flue Panel Rear ............................. 4050I/3600E .....................
20016706 Flue Panel Rear ............................. 4500I/4000E .....................
20016707 Flue Panel Rear ............................. 5000I/4500E .....................
20015001 Flue End Ext, Front Left ................ all ......................................
20015002 Flue End Ext, Front Right .............. all ......................................
20016802 Flue Panel Front ............................ 2450I/2200E .....................
20016803 Flue Panel Front ............................ 3050I/2800E .....................
20016804 Flue Panel Front ............................ 3500I/3200E .....................
20016805 Flue Panel Front ............................ 4050I/3600E .....................
20016806 Flue Panel Front ............................ 4500I/4000E .....................
20016807 Flue Panel Front ............................ 5000I/4500E .....................
20013700 Control Mounting Panel ................. all ......................................
20017700 Rear Middle Stand-Off ...............................................................
20017600 Upper Stand-Off Assy, Front & Rear ........................................
20061104 Junction Box Cover ....................... all ......................................
20013001 Boiler Top Support Assy ................ 2200-3050 ........................
20013002 Boiler Top Support Assy ................ 3200-4050 ........................
20013003 Boiler Top Support Assy ................ 4000-5000 ........................
20018202 Screen Retaining Angle ................. 2450I/2200E .....................
20018203 Screen Retaining Angle ................. 3050I/2800E .....................
20018204 Screen Retaining Angle ................. 3500I/3200E .....................
20018205 Screen Retaining Angle ................. 4050I/3600E .....................
20018206 Screen Retaining Angle ................. 4500I/4000E .....................
20018207 Screen Retaining Angle ................. 5000I/4500E .....................
20018302 Screen Retaining Strap ................. 2450I/2200E .....................
20018303 Screen Retaining Strap ................. 3050I/2800E .....................
20018304 Screen Retaining Strap ................. 3500I/3200E .....................
20018305 Screen Retaining Strap ................. 4050I/3600E .....................
20018306 Screen Retaining Strap ................. 4500I/4000E .....................
20018307 Screen Retaining Strap ................. 5000I/4500E .....................
20018400 Front Stiffener ................................ all ......................................
20018602 Upper Front & Rear Mesh
Screen ........................................... 2450I/2200E .....................
20018603 Upper Front & Rear Mesh
Screen ........................................... 3050I/2800E .....................
20018604 Upper Front & Rear Mesh
Screen ........................................... 3500I/3200E .....................
20018605 Upper Front & Rear Mesh
Screen ........................................... 4050I/3600E .....................
20018606 Upper Front & Rear Mesh
Screen ........................................... 4500I/4000E .....................
20018607 Upper Front & Rear Mesh
Screen ........................................... 5000I/4500E .....................
CROSS REFERENCE FOR NO LONGER AVAILABLE P/N'S
20001301
Complete Heat Exchanger Assy
(double pass, 18 tube) - NLA .......................... use K20001301
20001306 Complete Heat Exchanger Assy - NLA ........... use R20001306
20047801 Complete Pilot Assy - Spark, Nat. - NLA ........ use K20047801
E0013000 Flow Switch,outdoor - NLA
E0014400 Operating Control/Thermostat, On/Off
(100-240 F) - NLA ............................................ use KE0014400
E0015900 High Limit Switch, Manual Reset
(Temp Ctrl, 100-225 F) - NLA
E0086100 Transformer, 40VA - NLA .................................. use R0021300
E0100900 Ignition Control, Electronic, Nat - NLA ............ use KE0100900
E2033900 Ignition Control, Electronic. Spark LP/CSD-1
(100% Lockout) - NLA ..................................... use KE2033900
E2058300 Well, Aquastat - NLA
E2075100 Low Water Cut Off - NLA ................................ use RE2075100
L2005800 Burners - Newer style LB - NLA ...................... use KL2005800
V0046700 Safety Gas Valve - 4-Stage, Nat/LP - NLA
V0051300 Combination/Operating Gas Valve,
2-Stage, Nat - NLA .......................................... use KV0051300
W0030000 Relay, Shut Off - NLA ..................................... use KW0030000
W0034300 Pilot, HW, IID, Nat - NLA ................................ use KW0034300
W0034500 Pilot, JC, IID, Nat - NLA ................................. use KW0034500
MegaTherm AP, Sizes 2,000,000-5,000,000 MegaTherm AP, Sizes 2,000,000-5,000,000 MegaTherm AP, Sizes 2,000,000-5,000,000 MegaTherm AP, Sizes 2,000,000-5,000,000 MegaTherm AP, Sizes 2,000,000-5,000,000
Part No. Description Size Part No. Description Size
