8
MegaTherm MT, Sizes 2,000,000-5,000,000 MegaTherm MT, Sizes 2,000,000-5,000,000 MegaTherm MT, Sizes 2,000,000-5,000,000 MegaTherm MT, Sizes 2,000,000-5,000,000 MegaTherm MT, Sizes 2,000,000-5,000,000
Part No. Description Size Part No. Description Size
20011002 Lower Base Assy ........................... 2450I/2200E .....................
20011003 Lower Base Assy ........................... 3050I/2800E .....................
20011004 Lower Base Assy ........................... 3500I/3200E .....................
20011005 Lower Base Assy ........................... 4050I/3600E .....................
20011006 Lower Base Assy ........................... 4500I/4000E .....................
20011007 Lower Base Assy ........................... 5000I/4500E .....................
20011101 Rail Support Assy, End Tile, Left .. all ......................................
20011102 Rail Support Assy, End Tile, Right all ......................................
20102101 Gas Manifold Weldment
(single inlet) ................................... 2000 ..................................
20102102 Gas Manifold Weldment
(single inlet) ................................... 2450I/2200E .....................
20102103 Gas Manifold Weldment
(single inlet) ................................... 3050I/2800E .....................
20102104 Gas Manifold Weldment
(single inlet) ................................... 3500I/3200E .....................
20102601 Gas Manifold Weldment (dual inlet) 2000 .................................
20102602 Gas Manifold Weldment (dual inlet) 2450I/2200E ....................
20102603 Gas Manifold Weldment (dual inlet) 3050I/2800E ....................
20102604 Gas Manifold Weldment (dual inlet) 3500I/3200E ....................
20102605 Gas Manifold Weldment (dual inlet) 4050I/3600E ....................
20102606 Gas Manifold Weldment (dual inlet) 4500I/4000E ....................
20102607 Gas Manifold Weldment (dual inlet) 5000I/4500E ....................
20011401 Rear Tile Rail Assy ........................ 2000 ..................................
20011402 Rear Tile Rail Assy ........................ 2450I/2200E .....................
20011403 Rear Tile Rail Assy ........................ 3050I/2800E .....................
20011404 Rear Tile Rail Assy ........................ 3500I/3200E .....................
20011405 Rear Tile Rail Assy ........................ 4050I/3600E .....................
20011406 Rear Tile Rail Assy ........................ 4500I/4000E .....................
20011407 Rear Tile Rail Assy ........................ 5000I/4500E .....................
20011301 Front Tile Rail Assy ....................... 2000 ..................................
20011302 Front Tile Rail Assy ....................... 2450I/2200E .....................
20011303 Front Tile Rail Assy ....................... 3050I/2800E .....................
20011304 Front Tile Rail Assy ....................... 3500I/3200E .....................
20011305 Front Tile Rail Assy ....................... 4050I/3600E .....................
20011306 Front Tile Rail Assy ....................... 4500I/4000E .....................
20011307 Front Tile Rail Assy ....................... 5000I/4500E .....................
20012401 Rear Closure Assy ........................ 2000 ..................................
20012402 Rear Closure Assy ........................ 2450I/2200E .....................
20012403 Rear Closure Assy ........................ 3050I/2800E .....................
20012404 Rear Closure Assy ........................ 3500I/3200E .....................
20012405 Rear Closure Assy ........................ 4050I/3600E .....................
20012406 Rear Closure Assy ........................ 4500I/4000E .....................
20012407 Rear Closure Assy ........................ 5000I/4500E .....................
COMBUSTION CHAMBER COMPONENTS - Tile
20012101
Tile Heat Shield Assy (qty 2) ......... 2000 ..................................
20012102 Tile Heat Shield Assy (qty 2) ......... 2450I/2200E .....................
20012103 Tile Heat Shield Assy (qty 2) ......... 3050I/2800E .....................
20012104 Tile Heat Shield Assy (qty 2) ......... 3500I/3200E .....................
20012105 Tile Heat Shield Assy (qty 2) ......... 4050I/3600E .....................
20012106 Tile Heat Shield Assy (qty 2) ......... 4500I/4000E .....................
20012107 Tile Heat Shield Assy (qty 2) ......... 5000I/4500E .....................
20003201 Heat Shield Support ...................... 2000 ..................................
20003202 Heat Shield Support ...................... 2450I/2200E .....................
20003203 Heat Shield Support ...................... 3050I/2800E .....................
20003204 Heat Shield Support ...................... 3500I/3200E .....................
20003205 Heat Shield Support ...................... 4050I/3600E .....................
20003206 Heat Shield Support ...................... 4500I/4000E .....................
20003207 Heat Shield Support ...................... 5000I/4500E .....................
20004900 Center Support Assy .................................................................
20004901 End Bar Support Assy ...............................................................
20004902 Center Bar Support Assy ..........................................................
20005601 Center Heat Shield Panel .............. 2000 ..................................
20005602 Center Heat Shield Panel .............. 2450I/2200E .....................
20005603 Center Heat Shield Panel .............. 3050I/2800E .....................
20005604 Center Heat Shield Panel .............. 3500I/3200E .....................
20005605 Center Heat Shield Panel .............. 4050I/3600E .....................
20005606 Center Heat Shield Panel .............. 4500I/4000E .....................
20005607 Center Heat Shield Panel .............. 5000I/4500E .....................
20005701 Center Heat Shield Assy ............... 2000 ..................................
20005702 Center Heat Shield Assy ............... 2450I/2200E .....................
20005703 Center Heat Shield Assy ............... 3050I/2800E .....................
20005704 Center Heat Shield Assy ............... 3500I/3200E .....................
20005705 Center Heat Shield Assy ............... 4050I/3600E .....................
20005706 Center Heat Shield Assy ............... 4500I/4000E .....................
20005707 Center Heat Shield Assy ............... 5000I/4500E .....................
20002300 Tile end Shield, inner ..................... all ......................................
20005801 Tile Cover (qty 2) ........................... 2000 ..................................
20005802 Tile Cover (qty 2) ........................... 2450I/2200E .....................
20005803 Tile Cover (qty 2) ........................... 3050I/2800E .....................
20005804 Tile Cover (qty 2) ........................... 3500I/3200E .....................
20005805 Tile Cover (qty 2) ........................... 4050I/3600E .....................
20005806 Tile Cover (qty 2) ........................... 4500I/4000E .....................
20005807 Tile Cover (qty 2) ........................... 5000I/4500E .....................
10533601 Saddle Assy End Tile (qty 2) ......... all ......................................
20052701 Complete Tile Assy ........................ 2000 ..................................
20052702 Complete Tile Assy ........................ 2450I/2200E .....................
20052703 Complete Tile Assy ........................ 3050I/2800E .....................
20052704 Complete Tile Assy ........................ 3500I/3200E .....................
20052705 Complete Tile Assy ........................ 4050I/3600E .....................
20052706 Complete Tile Assy ........................ 4500I/4000E .....................
20052707 Complete Tile Assy ........................ 5000I/4500E .....................
20052501 Complete Pyro Tile Assy (AP) ....... 2000 ..................................
20052502 Complete Pyro Tile Assy (AP) ....... 2450I/2200E .....................
20052503 Complete Pyro Tile Assy (AP) ....... 3050I/2800E .....................
20052504 Complete Pyro Tile Assy (AP) ....... 3500I/3200E .....................
20052505 Complete Pyro Tile Assy (AP) ....... 4050I/3600E .....................
20052506 Complete Pyro Tile Assy (AP) ....... 4500I/4000E .....................
20052507 Complete Pyro Tile Assy (AP) ....... 5000I/4500E .....................
T2003800 End Tile, Left, ................................ all ......................................
T2003802 End Tile, Left (AP) ........................ all ......................................
T2003900 End Tile, Right, .............................. 2000-5000 ........................
T2003902 Tile, Pyro, End, Right (AP) ........... all ......................................
T2004000 Tile (17") ........................................ all ......................................
T2004002 Spacer Tile Front & Rear (AP) ..... all ......................................
T2006400 Tile (16") ........................................ 2000, 2200,
....................................................... 2450, 3200,
....................................................... 3500, 3600,
....................................................... 4050, 4500E,
....................................................... 5000 ..................................
T2006402 Tile, Pyro, Front & Rear
See T2006400 models ..............................................................
T2006500 Tile (9") - 2800, 3050, 4000, 4500I ...........................................
T2006502 Tile, Pyro, Front & Rear, Left
See T2006500 models ..............................................................
T2006600 Tile (15.38") ................................... 2000 ..................................
T2006602 Tile, Pyro, Front & Rear, Right ...... 2000 ..................................
T2006700 Tile (8.38") ..................................... 2200/2450 .........................
T2006702 Tile, Pyro, Front & Rear, Right ...... 2200/2450 .........................
T2006800 Tile (10.75") ................................... 2800/3050 .........................
T2006802 Tile, Pyro, Front & Rear, Right ...... 2800/3050 .........................
T2006900 Tile (13.75") ................................... 3200/3500 .........................
T2006902 Tile, Pyro, Front & Rear, Right ...... 3200/3500 .........................
