10417400 Flange, 4" cast iron (2 req) ............ all ......................................
10416100 Return Header (double pass) ........ all ......................................
20021100 Return Header, Bronze
(double pass) ................................. all ......................................
10416700 Return Header (single pass) ......... all ......................................
20010901 Baffle W/Bracket (68 req) .............. 2000 ..................................
20010902 Baffle W/Bracket (68 req) .............. 2450I/2200E .....................
20010903 Baffle W/Bracket (68 req) .............. 3050I/2800E .....................
20010904 Baffle W/Bracket (102 req) ............ 3500I/3200E .....................
20010905 Baffle W/Bracket (102 req) ............ 4050I/3600E .....................
20010906 Baffle W/Bracket (102 req) ............ 4500I/4000E .....................
20010907 Baffle W/Bracket (102 req) ............ 5000I/4500E .....................
10534310 Front & Rear HX Baffle .................. 2000 ..................................
10534306 Front & Rear HX Baffle .................. 2450I/2200E .....................
10534312 Front & Rear HX Baffle (4 req) ...... 3050I/2800E .....................
10534313 Front & Rear HX Baffle (4 req) ...... 3500I/3200E .....................
10534314 Front & Rear HX Baffle (6 req) ...... 4050I/3600E .....................
10534315 Front & Rear HX Baffle (6 req) ...... 4500I/4000E .....................
10534308 Front & Rear HX Baffle (6 req) ...... 5000I/4500E .....................
20012501 Inside Baffle Assy (indoor) ............ 2000 ..................................
20012502 Inside Baffle Assy (indoor) ............ 2450 ..................................
20012503 Inside Baffle Assy (indoor) ............ 3050 ..................................
20012504 Inside Baffle Assy (indoor) ............ 3500 ..................................
20012505 Inside Baffle Assy (indoor) ............ 4050 ..................................
20012506 Inside Baffle Assy (indoor) ............ 4500 ..................................
20012507 Inside Baffle Assy (indoor) ............ 5000 ..................................
20012509 Inside Baffle Assy (outdoor) .......... 2200 ..................................
20012510 Inside Baffle Assy (outdoor) .......... 2800 ..................................
20012511 Inside Baffle Assy (outdoor) .......... 3200 ..................................
20012512 Inside Baffle Assy (outdoor) .......... 3600 ..................................
20012513 Inside Baffle Assy (outdoor) .......... 4000 ..................................
20012514 Inside Baffle Assy (outdoor) .......... 4500 ..................................
20011501 Flue Panel Assy
Front & Rear (2 req) ...................... 2000 ..................................
20011502 Flue Panel Assy
Front & Rear (2 req) ...................... 2450I/2200E .....................
20011503 Flue Panel Assy
Front & Rear (2 req) ...................... 3050I/2800E .....................
20011504 Flue Panel Assy
Front & Rear (2 req) ...................... 3500I/3200E .....................
20011505 Flue Panel Assy
Front & Rear (2 req) ...................... 4050I/3600E .....................
20011506 Flue Panel Assy
Front & Rear (2 req) ...................... 4500I/4000E .....................
20011507 Flue Panel Assy
Front & Rear (2 req) ...................... 5000I/4500E .....................
20012000 Flue End Assy (2 req) .................... all ......................................
20032401 Baffle Support Strap (indoor) ........ 3500-5000 ........................
20032402 Baffle Support Strap (outdoor) ...... 3200-4500 ........................
JACKET COMPONENTS
20011601
Lower Panel Assy
Front & Rear (2 req) ...................... 2000 ..................................
20011602 Lower Panel Assy
Front & Rear (2 req) ...................... 2450I/2200E .....................
20011603 Lower Panel Assy
Front & Rear (2 req) ...................... 3050I/2800E .....................
20011604 Lower Panel Assy
Front & Rear (2 req) ...................... 3500I/3200E .....................
20011605 Lower Panel Assy
Front & Rear (2 req) ...................... 4050I/3600E .....................
20011606 Lower Panel Assy
Front & Rear (2 req) ...................... 4500I/4000E .....................
20011607 Lower Panel Assy
Front & Rear (2 req) ...................... 5000I/4500E .....................
20006401 Front & Rear Closure (2 req) ......... 2000 ..................................
20006402 Front & Rear Closure (2 req) ......... 2450I/2200E .....................
20006403 Front & Rear Closure (2 req) ......... 3050I/2800E .....................
20006404 Front & Rear Closure (2 req) ......... 3500I/3200E .....................
20006405 Front & Rear Closure (2 req) ......... 4050I/3600E .....................
20006406 Front & Rear Closure (2 req) ......... 4500I/4000E .....................
20006407 Front & Rear Closure (2 req) ......... 5000I/4500E .....................
20004301 Front Lower Closure ...................... 2000 ..................................
20004302 Front Lower Closure ...................... 2450I/2200E .....................
20004303 Front Lower Closure ...................... 3050I/2800E .....................
20004304 Front Lower Closure ...................... 3500I/3200E .....................
20004305 Front Lower Closure ...................... 4050I/3600E .....................
20004306 Front Lower Closure ...................... 4500I/4000E .....................
20004307 Front Lower Closure ...................... 5000I/4500E .....................
20016301 Lower Rear Closure Assy ............. 2000 ..................................
20016302 Lower Rear Closure Assy ............. 2450I/2200E .....................
20016303 Lower Rear Closure Assy ............. 3050I/2800E .....................
20016304 Lower Rear Closure Assy ............. 3500I/3200E .....................
20016305 Lower Rear Closure Assy ............. 4050I/3600E .....................
20016306 Lower Rear Closure Assy ............. 4500I/4000E .....................
20016307 Lower Rear Closure Assy ............. 5000I/4500E .....................
20011900 Upper End Panel Assy (2 req) ...... all ......................................
20011800 Lower End Panel Assy (2 req) ...... all ......................................
20011200 Control Box Cover Top ..............................................................
20058502 Commercial Control Box Cover .................................................
20300600 Weldment Control Box ..............................................................
20061402 Commercial Control Box ...........................................................
20097500 Control Mounting Panel Assy ....................................................
INDOOR PARTS
20011701
Upper Panel Assy
Front & Rear (2 req) ...................... 2000 ..................................
20011702 Upper Panel Assy
Front & Rear (2 req) ...................... 2450I/2200E .....................
20011703 Upper Panel Assy
Front & Rear (2 req) ...................... 3050I/2800E .....................
20011704 Upper Panel Assy
Front & Rear (2 req) ...................... 3500I/3200E .....................
20011705 Upper Panel Assy
Front & Rear (2 req) ...................... 4050I/3600E .....................
20011706 Upper Panel Assy
Front & Rear (2 req) ...................... 4500I/4000E .....................
20011707 Upper Panel Assy
Front & Rear (2 req) ...................... 5000I/4500E .....................
20012201 Flue Diverter Assy ......................... 2000 ..................................
20012202 Flue Diverter Assy ......................... 2450I/2200E .....................
20012203 Flue Diverter Assy ......................... 3050I/2800E .....................
20012204 Flue Diverter Assy ......................... 3500I/3200E .....................
20012205 Flue Diverter Assy ......................... 4050I/3600E .....................
20012206 Flue Diverter Assy ......................... 4500I/4000E .....................
20012207 Flue Diverter Assy ......................... 5000I/4500E .....................
20006301 Upper Wing Front, Left (2 req) ...... all ......................................
20006302 Upper Wing Front, Right (2 req) .... all ......................................
20012301 Top Panel Assy ............................. 2000 ..................................
20012302 Top Panel Assy ............................. 2450I/2200E .....................
20012303 Top Panel Assy ............................. 3050I/2800E .....................
20012304 Top Panel Assy ............................. 3500I/3200E .....................
20012305 Top Panel Assy ............................. 4050I/3600E .....................
20012306 Top Panel Assy ............................. 4500I/4000E .....................
20012307 Top Panel Assy ............................. 5000I/4500E .....................
MegaTherm MT, Sizes 2,000,000-5,000,000 MegaTherm MT, Sizes 2,000,000-5,000,000 MegaTherm MT, Sizes 2,000,000-5,000,000 MegaTherm MT, Sizes 2,000,000-5,000,000 MegaTherm MT, Sizes 2,000,000-5,000,000
Part No. Description Size Part No. Description Size
