Philips P-5759-D - Manual (Page 3)

Shipping Data
(Subject to change without notice)
Outer Case Case SKUs SKU Case Pallet
Product SKU UPC Bar Code Case Weight Cube Pallet Per Layers Dimensions Dimensions Dimensions
Number (0 46677-) (5 00 46677-) Qty. (lbs.) (cu. ft.) Qty. Layer High (W x D x H) (In.) (W x D x H) (In.) (W X D X H) (In.)
Halogen PAR16
26335-0
26335 5 26335 0 15 4.0 0.160 2160 360 6 2.1 x 2.1 x 3.3 7 x 11 x 4 39.36 x 42.76 x 23.28
26345-9 26345 4 26345 9 15 4.0 0.153 2160 360 6 2.1 x 2.1 x 3.3 7 x 11 x 4 39.36 x 42.76 x 23.28
33004-3 33004 0 33004 5 15 4.0 0.178 2160 360 6 2.1 x 2.1 x 3.3 7 x 11 x 4 39.36 x 42.76 x 23.28
33006-8 33006 4 33006 9 15 4.0 0.178 2160 360 6 2.1 x 2.1 x 3.3 7 x 11 x 4 39.36 x 42.76 x 23.28
26338-4 26338 6 26338 1 15 4.0 0.153 2160 360 6 2.1 x 2.1 x 3.3 7 x 11 x 4 39.36 x 42.76 x 23.28
26348-3 26348 5 26348 0 15 4.0 0.153 2160 360 6 2.1 x 2.1 x 3.3 7 x 11 x 4 39.36 x 42.76 x 23.28
33005-0 33005 7 33005 2 15 4.0 0.178 2160 360 6 2.1 x 2.1 x 3.3 7 x 11 x 4 39.36 x 42.76 x 23.28
33007-6 33007 1 33007 6 15 4.0 0.178 2160 360 6 2.1 x 2.1 x 3.3 7 x 11 x 4 39.36 x 42.76 x 23.28
Halogen PAR20
22906-2
22906 1 22906 6 15 4.0 0.241 2970 270 11 2.44 x 2.44 x 3.5 7.81 x 12.81 x 4.25 38.44 x 46.86 x 46.75
22911-2 22911 5 22911 0 15 4.0 0.241 2970 270 11 2.44 x 2.44 x 3.5 7.81 x 12.81 x 4.25 38.44 x 46.86 x 46.75
13846-1 13846 2 13846 7 15 4.0 0.250 2970 270 11 2.44 x 2.44 x 3.5 7.81 x 12.81 x 4.25 38.44 x 46.86 x 46.75
22921-1 22921 4 22921 9 15 4.0 0.241 2970 270 11 2.44 x 2.44 x 3.5 7.81 x 12.81 x 4.25 38.44 x 46.86 x 46.75
Halogen PAR30 Long Neck
22922-9
22922 1 22922 6 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22923-7 22923 8 22923 3 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22925-2 22925 2 22925 7 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22927-8 22927 6 22927 1 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22930-2 22930 6 22930 1 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22934-4 22934 4 22934 9 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22941-9 22941 2 22941 7 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22944-3 22944 3 22944 8 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
13847-9 13847 9 13847 4 15 8.0 0.630 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22926-0 22926 9 22926 4 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22928-6 22928 3 22928 8 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
13848-7 13848 6 13848 1 15 8.0 0.630 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22943-5 22943 6 22943 1 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
22945-0 22945 0 22945 5 15 8.0 0.688 1215 135 9 3.5 x 3.5 x 4.75 10.94 x 18.06 x 5.5 39.94 x 47.06 x 49.50
1) Rated average life is the length of operation (in hours) at which point an average of 50% of the
lamps will still be operational and 50% will not.
2) Maximum Beam Candlepower
3) To avoid deterioration of lampholder by heat, use only heat resistant lampholders or fixtures listed
by a nationally recognized electrical testing organization for use with reflector or PAR lamps.
4) PAR HALOGEN CAUTION NOTICE: Before using bulb, see operating instructions on
inside flap. Adherence to the operating instructions will reduce the risk of personal injury or fire.
The filament capsule contained inside this glass bulb is pressurized, operates at high temperature
and could unexpectedly shatter. Should the outer bulb break, particles of extremely hot glass
could be discharged into the fixture and/or the surrounding environment, thereby creating a risk of
personal injury or fire. Operating Instructions: Before replacing, turn off power and let lamp cool to
avoid electrical shock or burn.
— For indoor or outdoor use. A weather-protected fixture is recommended for wet locations.
— Suitable for use in open fixtures.
— Do not exceed the maximum wattage rating of the fixture.
— Do not use if outer glass is scratched or broken since it may break during operation or removal.
— If outer glass breaks the lamp may continue to light, however, immediately discontinue use.
— Due to the heat that radiates from the bulb, do not use in close proximity to combustible
materials or objects susceptible to drying or fading.
— Manage in accord with disposal laws.
Product Ordering Pkg Bulb Rated Avg. Approx. Class, MOL
Number Code Watts Volts Qty. Description Type Base Life (Hrs.) 1 MBCP 2 Lumens Filament (In.)
Halogen PAR38 3,4
22946-8 45PAR38/HAL/SP10 45 120 12 Spot 10º PAR-38 Medium Skirted 3000 6200 530 C, CC-8 5 5 ⁄
16
22948-4 45PAR38/HAL/FL25 45 120 12 Flood 25º PAR-38 Medium Skirted 3000 2000 530 C, CC-8 5 5 ⁄
16
14482-4 60PAR38/HAL/SP10 60 120 12 Spot 10º PAR-38 Medium Skirted 3000 10,500 800 C, CC-8 5 5 ⁄
16
14483-2 60PAR38/HAL/FL25 60 120 12 Flood 25º PAR-38 Medium Skirted 3000 3200 800 C, CC-8 5 5 ⁄
16
14484-0 60PAR38/HAL/WFL40 60 120 12 W. Flood 40º PAR-38 Medium Skirted 3000 1300 800 C, CC-8 5 5 ⁄
16
14485-7 75PAR38/HAL/SP10 75 120 12 Spot 10º PAR-38 Medium Skirted 3000 13,000 1050 C, CC-8 5 5 ⁄
16
14486-5 75PAR38/HAL/FL25 75 120 12 Flood 25º PAR-38 Medium Skirted 3000 3800 1050 C, CC-8 5 5 ⁄
16
23069-8 90PAR38/HAL/SP10 90 120 12 Spot 10º PAR-38 Medium Skirted 3000 16,400 1350 C, CC-8 5 5 ⁄
16
23070-6 90PAR38/HAL/FL25 90 120 12 Flood 25º PAR-38 Medium Skirted 3000 5350 1350 C, CC-8 5 5 ⁄
16
14487-3 90PAR38/HAL/WFL40 90 120 12 W. Flood 40º PAR-38 Medium Skirted 3000 2200 1350 C, CC-8 5 5 ⁄
16
22947-6 45PAR38/HAL/SP10 45 130 12 Spot 10º PAR-38 Medium Skirted 2500 6200 530 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 40W 5000 4960 410
22949-2 45PAR38/HAL/FL25 45 130 12 Flood 25º PAR-38 Medium Skirted 2500 2000 530 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 40W 5000 1600 410
14488-1 60PAR38/HAL/SP10 60 130 12 Spot 10º PAR-38 Medium Skirted 3000 10,500 800 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 53W 6000 8400 610
14490-7 60PAR38/HAL/FL25 60 130 12 Flood 25º PAR-38 Medium Skirted 3000 3200 800 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 53W 6000 2560 610
14491-5 60PAR38/HAL/WFL40 60 130 12 W. Flood 40º PAR-38 Medium Skirted 3000 1300 800 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 53W 6000 1040 610
14492-3 75PAR38/HAL/NSP8 75 130 12 N. Spot 8º PAR-38 Medium Skirted 2500 16,750 1100 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 66W 5000 13,400 840
14493-1 75PAR38/HAL/SP10 75 130 12 Spot 10º PAR-38 Medium Skirted 2500 14,000 1100 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 66W 5000 11,200 840
14494-9 75PAR38/HAL/FL25 75 130 12 Flood 25º PAR-38 Medium Skirted 2500 4350 1100 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 66W 5000 3480 1020
23650-5 90PAR38/HAL/SP10 90 130 12 Spot 10º PAR-38 Medium Skirted 2500 16,400 1350 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 79W 5000 13,120 1020
23651-3 90PAR38/HAL/FL25 90 130 12 Flood 25º PAR-38 Medium Skirted 2500 4500 1350 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 79W 5000 3800 1020
14495-5 90PAR38/HAL/WFL40 90 130 12 W. Flood 40º PAR-38 Medium Skirted 2500 2200 1350 C, CC-8 5 5 ⁄
16
Ratings @ 120V = 79W 5000 1760 1020
