PYLE Audio PT655E - Manual (Page 6)

EQUALIZER CHARACTERISTIC
Variable range…………………………………±12 dB/ (L & R independently adjustable)
Center frequencies…………………………….63Hz, 160Hz, 400Hz, 1KHz, 2.5KHz, 6.3 KHz, 16 kHz
Total harmonic distortion…………………….Less than 0.1% (20 Hz to 20 kHz)
Maximum output voltage…………………….6V (THD 0.05%)
S/N ratio……………………………………….60 dB (1HF-A network, 1 V)
Input impedance……………………………….47 kohms
Output impedance……………………………..15 kohms
General
Power consumption…………………………….10W
Power requirements
Power voltage………………………………….220V ~ 50Hz
For U.K…………………………………………240V ~ 50Hz
For U.S.A & Canada……………………………110V ~ 60Hz
Power consumption……………………………. 10 Watts maximum
Dimensions……………………………………….. 420 mm x 93 mm x 215 mm (W x H x L)
Weight……………………………………………..2.7 Kg
Note: We follow a policy of continuous advancements in development, for this reason specifications may be changed
without notice
