Job Information
Type:
"JSQPSU3PBE
'BMM3JWFS
."t t'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems
F7000-17
1BHFPG
'4FSJFT-JHIU5-PVWFS4JEF-FOT
&
CANDLEPOWER
ZONE
0
22
45
67
90
DEG.
CANDELAS
0
1260 1260 1260 1260 1260
5
1227 1246 1253 1262 1269
15
1074 1125 1211 1310 1363
25
871 961 1147 1331 1403
35
643 762 989 1055 1076
45
406 566 652 641 628
55
244 353 364 423 451
65
158 215 241 280 310
75
83 125 156 184 196
85
16
52
83 110 118
95
60 149 148 162 164
105
321 520 527 520 508
115
581 819 938 948 945
125
829 1046 1224 1322 1348
135
1033 1197 1427 1523 1551
145
1198 1301 1499 1618 1662
155
1317 1374 1486 1583 1620
165
1393 1413 1446 1483 1504
175
1424 1427 1418 1415 1418
180
1417 1417 1417 1417 1417
Performance
CANDLEPOWER CURVE
1600
1200
800
400
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
REPORT NO.: ITL54677.IES
LAMPS: 2-F54T5
LUMENS: 5000 each
EFFICIENCY: 81.7%
CAT. NO.: F7442WH214
DISTRIBUTION
Zone
Lumens
% Lamp
%Luminaire
0 - 90
2701
26.6
33.0
90 - 180
5491
55.1
67.0
0 - 180
8191
81.7
100.0
Mounting Accessories
Power Feed End Set:
F7EC36WH = White
F7EC36AL = Aluminum
F7EC36WHX4 = White 4 Wire
F7EC36ALX4 = Aluminum 4 Wire
F7EC36WHX5 = White 5 Wire
F7EC36ALX5 = Aluminum 5 Wire
Intermediate Power Cable
F7CC36 = 3 Wire
F7CC36X4 = 4 Wire
Intermediate Cable Set
F7C36
80%
70%
50%
50 30
10
50
30
10
50 30 10
0
85 85
85
76
76
76
61 61 61
1
74 70
67
67
64
62
53 51 49
2
65 60
56
59
54
51
47 44 42
3
57 51
47
51
47
43
42 38 35
4
50 45
40
46
41
36
37 33 30
5
46 39
34
41
35
31
33 29 27
6
41 34
29
37
31
28
30 26 23
7
36 30
26
33
28
24
28 23 20
8
33 27
23
30
25
21
25 21 18
9
30 25
20
28
23
19
23 19 16
10
28 22
18
26
20
17
21 17 14
20% FLOOR CAVITY REFLECTANCE
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
WALL REFLECTANCE
ROOM
CA
VITY
RA
TIO
“X” Joiner Block
F7XWH = White
F7XAL = Aluminum
12" (30.48cm)
“T” Joiner Block
F7TWH = White
F7TAL = Aluminum
6" (15.24cm)
12" (30.48cm)
“L” Joiner Block
F7LWH = White
F7LAL = Aluminum
6"
(15.24cm)
Fixture Lengths & Mounting Reflected (Plan View)
4'-0" (121.92cm)
8'-0" (243.84cm)
4'-0"
(121.92cm)
3/4" (1.91cm)
1-1/2"
(3.81cm)
3/8" (0.95cm)
END OF ROW DETAIL
GAP BETWEEN FIXTURES
JOINING DETAIL
4'-3" (129.54cm)
8'-0" (243.84cm)
4'-0" (121.92cm)
12'-3" (373.38cm)
8'-0" (243.84cm)
8'-0" (243.84cm)
16'-3" (495.30cm)
8'-3" (251.46cm)
8'-0" (243.84cm)
20'-3" (617.22cm)
8'-0" (243.84cm)
Inline Joiner Block
F7ILWH = White 1’ (30.48cm)
F7ILAL = Aluminum 1’ (30.48cm)
F7IL2WH = White 2’ (60.96cm)
F7IL2AL = Aluminum 2’(60.96cm)
F7IL4WH = White 4’ (121.92cm)
F7IL4AL = Aluminum 4’ (121.92cm)
F7IL8WH = White 8’ (243.84cm)
F7IL8AL = Aluminum 8’ (243.84cm)
12" (30.48cm)
