EFX546i Elliptical Fitness Crosstrainer Assembly Guide 7
Place one inner and one outer upright support cover (L)
around an upright support. Align each pair so the arrows
on the covers point toward the front of the unit.
Apply pressure to engage the inner cover protrusions with
the outer cover screw holes. Slide the covers down into
the base mounts. Secure each pair of covers using two
self-tapping screws (D) and a Phillips-head screwdriver.
Replace the lift cover removed in step 1. Insert the two
center crossbar caps (G) and press firmly into place. The
center crossbar caps hold the lift cover in place.
Attach the outer handrail caps (H) using four socket head
screws (F). Wrench tighten.
Position the water bottle holder as shown and attach it to
the right handrail. Secure the holder using three Phillips-
head screws (E) and a Phillips-head screwdriver.
C lean the ramp with a soft cloth dampened in a diluted
solution of mild soap and water.
