EFX546i Elliptical Fitness Crosstrainer Assembly Guide
4
Assembly Steps
R
emove the lift cover and set it aside.
Important: Grease on the lift axle can stain clothing. Be
careful not to get grease on your clothing as you remove
the lift cover.
Remove the two large handrail bolts from both upright
supports using the 1
⁵⁄₁₆-inch box-end wrench (K).
F
eed the cable through the right upright support. Tape
the cable to the top of the upright support to secure it
temporarily.
Important: Do not stretch, crimp, or damage the cable.
Cables damaged by improper installation will not be
covered by the Precor Limited Warranty.
