DialFire ISDN T1 (PRI), Short-Haul Configuration Worksheet 24
Model 2977 DialFire RAS User Manual 2 • Preparation
DialFire ISDN T1 (PRI), Short-Haul Configuration Worksheet
Use the worksheet below to collect the information that may be required to complete the configuration of your
DialFire PTE adapter within your operating system environment.
Note Not all operating systems support all parameters.
Note The parameters on this page are for ISDN T1 (PRI) connected to a PBX or similar
in-house network (Short Haul). If your adapter is connected directly to an external
T1 telephone line, use the ISDN T1 (PRI), Long Haul (External T1) configuration
worksheet (page 22).
Parameter Value
Coding [ ] B8ZS
Framing [ ] ESF
Short Haul Length in
feet (meters) [ ] 0–133 ft (0–41 m) [ ] 133–266 ft (40.5–81 m)
[ ] 266–399 ft (81–122 m) [ ] 399–533 ft (122–162 m)
[ ] 533–655 ft (162–200 m)
Signaling [ ] AT&T 5ESS [ ] Nortel DMS 100/250
[ ] ETSI (Euro ISDN) [ ] INS-1500 (Japan)
[ ] National ISDN2 [ ] None
NFAS Master Port (RAS
48 PT2 Only) [ ] None
[ ] 1 [ ] 2 Interface ID for Port
1(0–127): ________ Interface ID for
Port 2 (0–127):
________
Leased Time Slots List which, if any, PRI time slots are leased:
Modem Nationality Enter the country in which the PTE adapter will be installed:
