DialFire Channelized T1, Short-Haul Configuration Worksheet
20
Model 2977 DialFire RAS User Manual
2 • Preparation
DialFire Channelized T1, Short-Haul Configuration Worksheet
Use the worksheet below to collect the information that may be required to complete the configuration of your
DialFire PTE adapter within your operating system environment.
Note
Not all operating systems support all parameters.
Note
The parameters on this page are for channelized T1 connected to a PBX or similar in-
house network (Short Haul). If your adapter is connected directly to an external T1
telephone line, use the Channelized T1, Long Haul (External T1) worksheet on
page 19.
After completing the worksheet, go to chapter 3, “Installing the Model 2977 adapter” on page 26.
Parameter
Value
Coding
[ ] B8ZS [ ] AMI
Framing
[ ] ESF [ ] D4
Short Haul Length in feet (meters) [ ] 0–133 ft (0–41 m) [ ] 133–266 ft (40.5–81 m)
[ ] 266–399 ft (81–122 m) [ ] 399–533 ft (122–162 m)
[ ] 533–655 ft (162–200 m)
Signaling
[ ] Ground Start [ ] Loop Start [ ] Immediate Start [ ] Wink Start -- Wink
Patton Electronics (1-20): _________________
Leased Time Slots
List which, if any, T1 time slots are leased:
Modem Nationality
Enter the country in which the PTE adapter will be installed:
