UNASSEMBLED PARTS

Mower

(3) Retainer Springs (double loop)

(4) Retainer Springs (single loop)

(2) Front Link Assemblies

Gauge Wheels

(4) Washers 3/8 x 3/4 x 14 Ga.

(4) Wheels

(4) Adjusting
Bars

(4) Retainer Springs
(double loop)

(4) Clevis Pins

(4) Locknuts 3/8-16

(4) Shoulder

Bolts

Nose Roller

Nose
Roller
Brackets

(2) Hex Bolts

5/16-18 x 1

(2) Washers

17/32 x 7/8 x 16 Ga.

(2) Nylon
Locknuts
5/16-18

Steering Wheel

(1) Knob

(1) Washer
17/32 x 1-3/16 x 12 Gauge

Seat

Steering

Wheel Insert

Steering

Wheel Adapter

Steering Sleeve

Steering Sleeve

Extension

(1) Oil Drain Tube
For Future Use

(2) Keys

Slope Sheet

Keys

(3) Mulching

Blades

Blades
